Part Details for ADM6713SAKSZ-REEL by Analog Devices Inc
Results Overview of ADM6713SAKSZ-REEL by Analog Devices Inc
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (5 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Renewable Energy
Automotive
ADM6713SAKSZ-REEL Information
ADM6713SAKSZ-REEL by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for ADM6713SAKSZ-REEL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
ADM6713SAKSZ-REELCT-ND
|
DigiKey | IC SUPERVISOR 1 CHANNEL SC70-4 Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
6589 In Stock |
|
$0.4625 / $1.9200 | Buy Now |
|
DISTI #
584-ADM6713SAKSZ-R
|
Mouser Electronics | Supervisory Circuits Microprocessor Reset Circuit. I.C. RoHS: Compliant | 4901 |
|
$0.4800 / $1.8300 | Buy Now |
|
DISTI #
V72:2272_06220637
|
Arrow Electronics | Processor Supervisor 2.93V 1 Active Low/Open Drain 4-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2248 Container: Cut Strips | Americas - 8364 |
|
$0.4745 / $0.5390 | Buy Now |
|
DISTI #
26634948
|
Verical | Processor Supervisor 2.93V 1 Active Low/Open Drain 4-Pin SC-70 T/R RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 | Americas - 20000 |
|
$0.4576 | Buy Now |
|
DISTI #
69196188
|
Verical | Processor Supervisor 2.93V 1 Active Low/Open Drain 4-Pin SC-70 T/R RoHS: Compliant Min Qty: 13 Package Multiple: 1 Date Code: 2248 | Americas - 8364 |
|
$0.4745 / $0.5309 | Buy Now |
|
|
Rochester Electronics | Microprocessor Supervisory Circuit RoHS: Compliant Status: Active Min Qty: 1 | 558 |
|
$0.3895 / $0.6282 | Buy Now |
|
|
LCSC | 240ms Active Low 1V5.5V 1 SC-70-4 Supervisor and Reset ICs ROHS | 50 |
|
$0.7816 / $1.2704 | Buy Now |
|
|
Win Source Electronics | Microprocessor Supervisory Circuit in 4-Lead SC70 | IC SUPERVISOR MPU 2.93V SC70-4 | 38290 |
|
$0.5391 / $0.6962 | Buy Now |
Part Details for ADM6713SAKSZ-REEL
ADM6713SAKSZ-REEL CAD Models
ADM6713SAKSZ-REEL Part Data Attributes
|
|
ADM6713SAKSZ-REEL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADM6713SAKSZ-REEL
Analog Devices Inc
Microprocessor Supervisory Circuit in 4-Lead SC70
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | ROHS COMPLIANT, EIAJ SC82, SC-70, 4 PIN | |
| Pin Count | 4 | |
| Manufacturer Package Code | KS-4 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | VOLTAGE SUPERVISOR/RESET IC | |
| JESD-30 Code | R-PDSO-G4 | |
| JESD-609 Code | e3 | |
| Length | 2 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 4 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | SOT-343R | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Supply Current-Max (Isup) | 0.03 mA | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 1.2 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Threshold Voltage-Nom | +2.93V | |
| Width | 1.25 mm |
