Part Details for ADG706BRUZ-REEL by Analog Devices Inc
Results Overview of ADG706BRUZ-REEL by Analog Devices Inc
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (4 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Aerospace and Defense
Communication and Networking
ADG706BRUZ-REEL Information
ADG706BRUZ-REEL by Analog Devices Inc is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LMX2325TMX-G | Rochester Electronics LLC | LMX2325 - RoHS - T/R, PLL Freq Synthesizer | |
| HSCHD02CR2001R | Amphenol Communications Solutions | HSC Right Angle plug,Tape and Reel,Brown housing | |
| HSCHD02BR1001R | Amphenol Communications Solutions | HSC Right Angle plug,Tape and Reel,Blue housing |
Price & Stock for ADG706BRUZ-REEL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
47AK3406
|
Newark | Multiplexer, Analogue, Tssop, Ic Function:Analog Multiplexer, Power Supply Type:Single & Dual Supply, Supply Voltage Range:1.8V To 5.5V, ± 2.25V To ± 2.75V, Ic Case/Package:Tssop, No. Of Pins:28Pins, No. Of Channels:1Channels Rohs Compliant: Yes |Analog Devices ADG706BRUZ-REEL RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1717 |
|
$4.6200 / $7.2800 | Buy Now |
|
DISTI #
ADG706BRUZ-REELCT-ND
|
DigiKey | IC MUX 16:1 4.5OHM 28TSSOP Min Qty: 1 Lead time: 10 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
4614 In Stock |
|
$4.5625 / $9.9700 | Buy Now |
|
DISTI #
584-ADG706BRUZ-R
|
Mouser Electronics | Multiplexer Switch ICs 16-ch MPX RoHS: Compliant | 15265 |
|
$4.5600 / $6.5100 | Buy Now |
|
DISTI #
V72:2272_06219256
|
Arrow Electronics | Analog Multiplexer Single 16:1 28-Pin TSSOP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2304 Container: Cut Strips | Americas - 1 |
|
$5.4500 / $6.4970 | Buy Now |
|
|
Analog Devices Inc | 16-ch MPX Min Qty: 2500 Package Multiple: 2500 | 2500 |
|
$3.2700 / $9.9700 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 3595 |
|
RFQ | |
|
|
Win Source Electronics | IC MULTIPLEXER 16X1 28TSSOP | 31910 |
|
$2.8333 / $3.6597 | Buy Now |
Part Details for ADG706BRUZ-REEL
ADG706BRUZ-REEL CAD Models
ADG706BRUZ-REEL Part Data Attributes
|
|
ADG706BRUZ-REEL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADG706BRUZ-REEL
Analog Devices Inc
CMOS, 2.5 Ω Low Voltage 16 Channel Multiplexer
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SSOP | |
| Package Description | TSSOP-28 | |
| Pin Count | 28 | |
| Manufacturer Package Code | RU-28 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | CAN ALSO OPERATE WITH SINGLE 3V OR SINGLE 5V SUPPLIES | |
| Analog IC - Other Type | SPST | |
| JESD-30 Code | R-PDSO-G28 | |
| JESD-609 Code | e3 | |
| Length | 9.7 mm | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage-Max (Vsup) | -2.75 V | |
| Neg Supply Voltage-Min (Vsup) | -2.25 V | |
| Neg Supply Voltage-Nom (Vsup) | -2.5 V | |
| Number of Channels | 16 | |
| Number of Functions | 1 | |
| Number of Terminals | 28 | |
| Off-state Isolation-Nom | 80 dB | |
| On-state Resistance Match-Nom | 0.3 Ω | |
| On-state Resistance-Max (Ron) | 4.5 Ω | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP28,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 mm | |
| Signal Current-Max | 0.03 A | |
| Supply Current-Max (Isup) | 0.001 mA | |
| Supply Voltage-Max (Vsup) | 2.75 V | |
| Supply Voltage-Min (Vsup) | 2.25 V | |
| Supply Voltage-Nom (Vsup) | 2.5 V | |
| Surface Mount | YES | |
| Switch-off Time-Max | 26 ns | |
| Switch-on Time-Max | 50 ns | |
| Switching | BREAK-BEFORE-MAKE | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 mm |
Alternate Parts for ADG706BRUZ-REEL
This table gives cross-reference parts and alternative options found for ADG706BRUZ-REEL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ADG706BRUZ-REEL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ADG706BRUZ-REEL7 | Analog Devices Inc | $5.3621 | CMOS, 2.5 Ω Low Voltage 16 Channel Multiplexer | ADG706BRUZ-REEL vs ADG706BRUZ-REEL7 |
| ADG706BRUZ | Analog Devices Inc | $5.7843 | CMOS, 2.5 Ω Low Voltage 16 Channel Multiplexer | ADG706BRUZ-REEL vs ADG706BRUZ |
| ADG706BRU-REEL7 | Analog Devices Inc | Check for Price | CMOS, 2.5 Ω Low Voltage 16 Channel Multiplexer | ADG706BRUZ-REEL vs ADG706BRU-REEL7 |
| ADG706BRU-REEL | Analog Devices Inc | Check for Price | IC 16-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO28, TSSOP-28, Multiplexer or Switch | ADG706BRUZ-REEL vs ADG706BRU-REEL |
