ADBMS6832MWCCSZ-RL Information
ADBMS6832MWCCSZ-RL by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for ADBMS6832MWCCSZ-RL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Analog Devices Inc | 18 Ch Multicell Mon Min Qty: 2500 Package Multiple: 2500 | 0 |
|
$9.4100 / $12.9400 | Buy Now |
|
|
LCSC | LFCSP-64-EP(9x9) Battery Management ROHS | 210 |
|
$5.3571 / $7.6971 | Buy Now |
Part Details for ADBMS6832MWCCSZ-RL
ADBMS6832MWCCSZ-RL CAD Models
ADBMS6832MWCCSZ-RL Part Data Attributes
|
|
ADBMS6832MWCCSZ-RL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADBMS6832MWCCSZ-RL
Analog Devices Inc
18-Channel Multicell Battery Monitor, LFCSP SIDESOLDERABLE, 64 Pins, -40 to 125C
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | LFCSP SIDESOLDERABLE | |
| Package Description | LFCSP-64 | |
| Pin Count | 64 | |
| Manufacturer Package Code | LFCSP SIDESOLDERABLE | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | BATTERY MONITOR | |
| JESD-30 Code | S-XQCC-N64 | |
| Length | 9 mm | |
| Number of Channels | 18 | |
| Number of Functions | 1 | |
| Number of Terminals | 64 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC64,.35SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 0.8 mm | |
| Surface Mount | YES | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 9 mm |
