Part Details for ADA4899-1YRDZ-RL by Analog Devices Inc
Results Overview of ADA4899-1YRDZ-RL by Analog Devices Inc
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (3 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
ADA4899-1YRDZ-RL Information
ADA4899-1YRDZ-RL by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for ADA4899-1YRDZ-RL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
ADA4899-1YRDZ-RLTR-ND
|
DigiKey | IC VOLTAGE FEEDBACK 1 CIRC 8SOIC Min Qty: 2500 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$3.0375 | Buy Now |
|
DISTI #
584-ADA4899-1YRDZ-R
|
Mouser Electronics | High Speed Operational Amplifiers Ultra Low Noise and Distortion Hi Speed RoHS: Compliant | 0 |
|
$3.0300 | Order Now |
|
|
Analog Devices Inc | Ultra Low Noise and Distortion Min Qty: 2500 Package Multiple: 2500 | 2500 |
|
$2.2500 / $7.3800 | Buy Now |
|
|
Rochester Electronics | ADA4899 - Operational Amplifier, 230uV Offset-Max, BIPolar, PDSO8 RoHS: Compliant Status: Active Min Qty: 1 | 32 |
|
$2.5500 / $3.1900 | Buy Now |
|
|
LCSC | Single channel 12uA 310V/us 230uV SOIC-8-EP Operational Amplifier ROHS | 35 |
|
$3.8654 / $5.5392 | Buy Now |
|
|
Vyrian | Amplifiers | 1620 |
|
RFQ | |
|
|
Win Source Electronics | IC OPAMP VFB 1 CIRCUIT 8SOIC / Unity-Gain Stable, Ultralow Distortion, 1 nV/√Hz Voltage Noise, High Speed Op Amp | 3670 |
|
$3.2726 / $4.2270 | Buy Now |
Part Details for ADA4899-1YRDZ-RL
ADA4899-1YRDZ-RL CAD Models
ADA4899-1YRDZ-RL Part Data Attributes
|
|
ADA4899-1YRDZ-RL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADA4899-1YRDZ-RL
Analog Devices Inc
Unity-Gain Stable, Ultralow Distortion, 1 nV/√Hz Voltage Noise, High Speed Op Amp
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | RD-8-1 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Amplifier Type | OPERATIONAL AMPLIFIER | |
| Architecture | VOLTAGE-FEEDBACK | |
| Average Bias Current-Max (IIB) | 12 µA | |
| Bandwidth (3dB)-Nom | 600 MHz | |
| Common-mode Reject Ratio-Min | 98 dB | |
| Common-mode Reject Ratio-Nom | 130 dB | |
| Input Offset Current-Max (IIO) | 0.7 µA | |
| Input Offset Voltage-Max | 230 µV | |
| JESD-30 Code | R-XDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Low-Bias | NO | |
| Low-Offset | YES | |
| Micropower | NO | |
| Moisture Sensitivity Level | 3 | |
| Neg Supply Voltage Limit-Max | -5 V | |
| Neg Supply Voltage-Nom (Vsup) | -5 V | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HSOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power | NO | |
| Programmable Power | NO | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Slew Rate-Nom | 310 V/us | |
| Supply Current-Max | 16.2 mA | |
| Supply Voltage Limit-Max | 12 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Voltage Gain-Min | 82 | |
| Wideband | YES | |
| Width | 3.9 mm |
Alternate Parts for ADA4899-1YRDZ-RL
This table gives cross-reference parts and alternative options found for ADA4899-1YRDZ-RL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ADA4899-1YRDZ-RL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ADA4899-1YRDZ-R7 | Rochester Electronics LLC | Check for Price | OP-AMP, 230 uV OFFSET-MAX, PDSO8, ROHS COMPLIANT, MS-012AA, SOIC-8 | ADA4899-1YRDZ-RL vs ADA4899-1YRDZ-R7 |
ADA4899-1YRDZ-RL Frequently Asked Questions (FAQ)
-
A good PCB layout for the ADA4899-1YRDZ-RL involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing decoupling capacitors close to the power pins. Additionally, it's recommended to use a low-ESR capacitor for the power supply bypassing.
-
The choice of gain resistors for the ADA4899-1YRDZ-RL depends on the desired gain and bandwidth. A good starting point is to use 1% or 0.1% tolerance resistors with a value between 1 kΩ and 10 kΩ. The datasheet provides a gain resistor selection table to help with the calculation.
-
The maximum power dissipation of the ADA4899-1YRDZ-RL is 1.3 W, which is calculated based on the maximum junction temperature (150°C) and the thermal resistance of the package (125°C/W). It's essential to ensure that the device is properly heat-sinked to prevent overheating.
-
Yes, the ADA4899-1YRDZ-RL can be used in a single-supply configuration, but it requires careful consideration of the input common-mode voltage range and the output voltage swing. The datasheet provides guidance on how to configure the device for single-supply operation.
-
To protect the ADA4899-1YRDZ-RL from ESD and overvoltage, it's recommended to use ESD protection diodes and TVS (transient voltage suppression) diodes on the input and output pins. Additionally, ensure that the device is handled and stored in an ESD-safe environment.
