AD974ARSZ Information
AD974ARSZ by Analog Devices Inc is an Other Telecom IC.
Other Telecom ICs are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for AD974ARSZ
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
49AK9974
|
Newark | Adc, 16Bit, 200Ksps, Ssop-28, Resolution (Bits):16Bit, Sampling Rate:200Ksps, Input Channel Type:Single Ended, Data Interface:Serial, Spi, Supply Voltage Type:Single, Supply Voltage Min:4.75V, Supply Voltage Max:5.25V Rohs Compliant: Yes |Analog Devices AD974ARSZ RoHS: Not Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 9 |
|
$60.3600 / $82.9100 | Buy Now |
|
DISTI #
AD974ARSZ-ND
|
DigiKey | IC DAS 16BIT 200K 28SSOP Min Qty: 1 Lead time: 10 Weeks Container: Tube |
35 In Stock |
|
$60.3620 / $74.7100 | Buy Now |
|
DISTI #
584-AD974ARSZ
|
Mouser Electronics | Analog to Digital Converters - ADC 4-Channel 16 Bit 200kSPS Data Acq System RoHS: Compliant | 50 |
|
$62.7100 / $81.5800 | Buy Now |
|
|
Analog Devices Inc | 4-Channel 16 Bit 200kSPS Data Package Multiple: 1 | 105758 |
|
$44.9300 / $74.7100 | Buy Now |
|
DISTI #
27157549
|
Verical | 4-Channel Single ADC 200ksps 16-bit Serial 28-Pin SSOP Tube RoHS: Compliant Min Qty: 10 Package Multiple: 10 | Americas - 105750 |
|
$60.7421 | Buy Now |
|
DISTI #
AD974ARSZ
|
Richardson RFPD | CONVERTER - ADC RoHS: Compliant Min Qty: 10 | 0 |
|
$63.1500 / $70.3700 | Buy Now |
Part Details for AD974ARSZ
AD974ARSZ CAD Models
AD974ARSZ Part Data Attributes
|
|
AD974ARSZ
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD974ARSZ
Analog Devices Inc
4-Channel, 16-Bit, 200 kSPS Data Acquisition System
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SSOP | |
| Package Description | SSOP-28 | |
| Pin Count | 28 | |
| Manufacturer Package Code | RS-28 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| JESD-30 Code | R-PDSO-G28 | |
| JESD-609 Code | e3 | |
| Length | 10.2 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 28 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2 mm | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Telecom IC Type | TELECOM CIRCUIT | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5.3 mm |
