AD9735BBCZ Information
AD9735BBCZ by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD9735BBCZ
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
4387957
|
Farnell | D/A CONVERTER, 12BIT, -40 TO 85DEG C RoHS: Compliant Min Qty: 1 Lead time: 21 Weeks, 1 Days Container: Each | 16 |
|
$41.1786 / $55.6888 | Buy Now |
|
DISTI #
AD9735BBCZ-ND
|
DigiKey | IC DAC 12BIT A-OUT 160CSPBGA Min Qty: 1 Lead time: 13 Weeks Container: Tray |
20 In Stock |
|
$37.7625 / $51.0600 | Buy Now |
|
DISTI #
584-AD9735BBCZ
|
Mouser Electronics | Digital to Analog Converters - DAC 12-Bit 1.2 GSPS DAC RoHS: Compliant | 28 |
|
$37.7600 / $51.0800 | Buy Now |
|
|
Analog Devices Inc | 12-Bit 1.2 GSPS DAC Package Multiple: 1 | 274 |
|
$28.0400 / $51.0600 | Buy Now |
|
DISTI #
26617369
|
Verical | DAC 1-CH Interpolation Filter 12-bit 160-Pin CSP-BGA Tray RoHS: Compliant Min Qty: 16 Package Multiple: 16 | Americas - 256 |
|
$37.3655 | Buy Now |
|
DISTI #
AD9735BBCZ
|
Richardson RFPD | CONVERTER - DAC RoHS: Compliant Min Qty: 16 | 0 |
|
$39.5000 / $44.0200 | Buy Now |
Part Details for AD9735BBCZ
AD9735BBCZ CAD Models
AD9735BBCZ Part Data Attributes
|
|
AD9735BBCZ
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD9735BBCZ
Analog Devices Inc
12-Bit, 1200 MSPS DACs
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | BGA | |
| Package Description | LEAD FREE, MO-205AE, CSPBGA-160 | |
| Pin Count | 160 | |
| Manufacturer Package Code | BC-160-1 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Output Voltage-Max | 1 V | |
| Analog Output Voltage-Min | -1 V | |
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY, 2'S COMPLEMENT BINARY | |
| Input Format | SERIAL | |
| JESD-30 Code | S-XBGA-B160 | |
| JESD-609 Code | e1 | |
| Length | 12 mm | |
| Linearity Error-Max (EL) | 0.0366% | |
| Moisture Sensitivity Level | 3 | |
| Number of Bits | 12 | |
| Number of Functions | 1 | |
| Number of Terminals | 160 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | LFBGA | |
| Package Equivalence Code | BGA160,14X14,32 | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.4 mm | |
| Supply Voltage-Nom | 1.8 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | BALL | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | BOTTOM | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 12 mm |
