AD9571ACPZPEC Information
AD9571ACPZPEC by Analog Devices Inc is a Clock Driver.
Clock Drivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for AD9571ACPZPEC
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
AD9571ACPZPEC-ND
|
DigiKey | IC CLOCK GENERATOR 40LFCSP Min Qty: 1 Lead time: 10 Weeks Container: Tray |
60 In Stock |
|
$9.1000 / $16.7600 | Buy Now |
|
DISTI #
584-AD9571ACPZPEC
|
Mouser Electronics | Clock Generators & Support Products Dual PLL Clock Generator for Fibre Chann RoHS: Compliant | 68 |
|
$9.1000 / $16.2100 | Buy Now |
|
DISTI #
V36:1790_06216435
|
Arrow Electronics | Clock Generator 25MHz-IN 156.25MHz-OUT 40-Pin LFCSP EP Tray RoHS: Compliant Min Qty: 68 Package Multiple: 68 Lead time: 10 Weeks Date Code: 2102 | Americas - 1 |
|
$8.5000 | Buy Now |
|
|
Analog Devices Inc | Dual PLL Clock Generator for F Package Multiple: 1 | 14 |
|
$6.7400 / $16.7600 | Buy Now |
|
|
Rochester Electronics | PLL Based Clock Driver, CMOS Series, 10 True Output(s), 10 Inverted Output(s), CMOS RoHS: Compliant Status: Active Min Qty: 1 | 25 |
|
$7.6600 / $9.5800 | Buy Now |
|
|
LCSC | 156.25MHz LFCSP-40(6x6) Clock Generators PLLs Frequency Synthesizers ROHS | 80 |
|
$15.8519 / $20.0876 | Buy Now |
Part Details for AD9571ACPZPEC
AD9571ACPZPEC CAD Models
AD9571ACPZPEC Part Data Attributes
|
|
AD9571ACPZPEC
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD9571ACPZPEC
Analog Devices Inc
Ethernet Clock Generator, 10 Clock Outputs
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFN | |
| Package Description | LFCSP_WQ-40 | |
| Pin Count | 40 | |
| Manufacturer Package Code | CP-40-7 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Family | CMOS | |
| Input Conditioning | STANDARD | |
| JESD-30 Code | S-XQCC-N40 | |
| JESD-609 Code | e3 | |
| Length | 6 mm | |
| Logic IC Type | PLL BASED CLOCK DRIVER | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Inverted Outputs | 10 | |
| Number of Terminals | 40 | |
| Number of True Outputs | 10 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC40,.24SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 6 mm | |
| fmax-Min | 25 MHz |
