3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for AD8607ARZ-REEL by Analog Devices Inc
Results Overview of AD8607ARZ-REEL by Analog Devices Inc
- Distributor Offerings: (9 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (7 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Industrial Automation
Electronic Manufacturing
AD8607ARZ-REEL Information
AD8607ARZ-REEL by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for AD8607ARZ-REEL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
60AK7644
|
Newark | Op-Amp, 400Khz, -40 To 125Deg C, Nsoic-8, No. Of Channels:2Channels, Gain Bandwidth Product:400Khz, Supply Voltage Range:1.8V To 5V, Ic Case/Package:Nsoic, No. Of Pins:8Pins, Amplifier Type:Cmos, Input Offset Voltage:12Μv Rohs Compliant: Yes |Analog Devices AD8607ARZ-REEL RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 760 |
|
$1.9700 / $3.6300 | Buy Now |
|
DISTI #
AD8607ARZ-REELCT-ND
|
DigiKey | IC CMOS 2 CIRCUIT 8SOIC Min Qty: 1 Lead time: 20 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
3121 In Stock |
|
$1.9500 / $5.3400 | Buy Now |
|
DISTI #
584-AD8607ARZ-R
|
Mouser Electronics | Precision Amplifiers DUAL, PRECISION CMOS RAIL-RAIL OP AMP RoHS: Compliant | 3939 |
|
$1.9500 / $3.4800 | Buy Now |
|
DISTI #
V72:2272_06214997
|
Arrow Electronics | Op Amp Dual Low Noise Amplifier R-R I/O ±2.5V/5V 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 20 Weeks Date Code: 2340 Container: Cut Strips | Americas - 990 |
|
$2.0940 / $2.7220 | Buy Now |
|
|
Analog Devices Inc | DUAL, PRECISION CMOS RAIL-RAIL Min Qty: 2500 Package Multiple: 2500 | 2500 |
|
$1.9500 / $5.3400 | Buy Now |
|
DISTI #
73478978
|
Verical | Op Amp Dual Low Noise Amplifier R-R I/O ±2.5V/5V 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2340 | Americas - 990 |
|
$2.0940 / $2.7220 | Buy Now |
|
|
Quest Components | OPERATIONAL AMPLIFIER, 2 FUNC, 700UV OFFSET-MAX, CMOS, PDSO8 | 8000 |
|
$3.7397 / $7.4793 | Buy Now |
|
|
Vyrian | Amplifiers | 3080 |
|
RFQ | |
|
|
Win Source Electronics | Precision Micropower, Low Noise CMOS Rail-to-Rail Input/Output Operational Amplifiers | IC OPAMP GP 2 CIRCUIT 8SOIC | 7760 |
|
$1.2513 / $1.6162 | Buy Now |
Part Details for AD8607ARZ-REEL
AD8607ARZ-REEL CAD Models
AD8607ARZ-REEL Part Data Attributes
|
|
AD8607ARZ-REEL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD8607ARZ-REEL
Analog Devices Inc
Precision Dual MicroPower Rail-to-Rail Input/Output Amplifier
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Pin Count | 8 | |
| Manufacturer Package Code | R-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Amplifier Type | OPERATIONAL AMPLIFIER | |
| Architecture | VOLTAGE-FEEDBACK | |
| Average Bias Current-Max (IIB) | 0.0005 µA | |
| Bias Current-Max (IIB) @25C | 0.000001 µA | |
| Common-mode Reject Ratio-Nom | 98 dB | |
| Frequency Compensation | YES | |
| Input Offset Voltage-Max | 700 µV | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Low-Bias | YES | |
| Low-Offset | YES | |
| Micropower | YES | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage Limit-Max | ||
| Neg Supply Voltage-Nom (Vsup) | ||
| Number of Functions | 2 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Slew Rate-Nom | 0.1 V/us | |
| Supply Current-Max | 0.12 mA | |
| Supply Voltage Limit-Max | 6 V | |
| Supply Voltage-Nom (Vsup) | 1.8 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Unity Gain BW-Nom | 385 | |
| Voltage Gain-Min | 100000 | |
| Width | 3.9 mm |
Alternate Parts for AD8607ARZ-REEL
This table gives cross-reference parts and alternative options found for AD8607ARZ-REEL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AD8607ARZ-REEL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| AD8607ARZ | Analog Devices Inc | $2.4312 | Precision Dual MicroPower Rail-to-Rail Input/Output Amplifier | AD8607ARZ-REEL vs AD8607ARZ |
| AD8607ARMZ | Analog Devices Inc | $2.6561 | Precision Dual MicroPower Rail-to-Rail Input/Output Amplifier | AD8607ARZ-REEL vs AD8607ARMZ |
| AD8607ARMZ-REEL | Analog Devices Inc | $2.7556 | Precision Dual MicroPower Rail-to-Rail Input/Output Amplifier | AD8607ARZ-REEL vs AD8607ARMZ-REEL |
| AD8607AR | Analog Devices Inc | Check for Price | IC DUAL OP-AMP, 700 uV OFFSET-MAX, 0.385 MHz BAND WIDTH, PDSO8, MS-012AA, SOIC-8, Operational Amplifier | AD8607ARZ-REEL vs AD8607AR |
| AD8607ARM-REEL | Analog Devices Inc | Check for Price | DUAL OP-AMP, 700uV OFFSET-MAX, 0.385MHz BAND WIDTH, PDSO8, MO-187AA, MSOP-8 | AD8607ARZ-REEL vs AD8607ARM-REEL |
| AD8607ARMZ-R2 | Analog Devices Inc | Check for Price | IC DUAL OP-AMP, 700 uV OFFSET-MAX, 0.385 MHz BAND WIDTH, PDSO8, ROHS COMPLIANT, MO-187AA, MSOP-8, Operational Amplifier | AD8607ARZ-REEL vs AD8607ARMZ-R2 |
| AD8607ARM-R2 | Analog Devices Inc | Check for Price | IC DUAL OP-AMP, 700 uV OFFSET-MAX, 0.385 MHz BAND WIDTH, PDSO8, MO-187AA, MSOP-8, Operational Amplifier | AD8607ARZ-REEL vs AD8607ARM-R2 |
AD8607ARZ-REEL Frequently Asked Questions (FAQ)
-
The maximum power dissipation of the AD8607ARZ-REEL is 670mW, which is calculated based on the maximum junction temperature (TJ) of 150°C and the thermal resistance (θJA) of 125°C/W.
-
To ensure stability, it's essential to follow proper PCB layout practices, use a low-ESR capacitor for decoupling, and consider adding a capacitor in parallel with the feedback resistor to reduce the phase margin.
-
The recommended input voltage range for the AD8607ARZ-REEL is between 2V and VCC-1.5V, where VCC is the supply voltage. Exceeding this range may lead to reduced performance or even damage to the device.
-
While the AD8607ARZ-REEL can be used as a comparator, it's not the most suitable choice due to its relatively slow slew rate and limited bandwidth. A dedicated comparator like the AD8561 or AD9671 would be a better option.
-
To prevent electrostatic discharge (ESD) damage, handle the AD8607ARZ-REEL by the body, use an anti-static wrist strap or mat, and ensure that the PCB has proper ESD protection circuits, such as TVS diodes or ESD protection arrays.
