AD8030ARJZ-REEL7 Information
AD8030ARJZ-REEL7 by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for AD8030ARJZ-REEL7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
80AK4589
|
Newark | Op-Amp, 125Mhz, -40 To 125Deg C, Sot-23 Rohs Compliant: Yes |Analog Devices AD8030ARJZ-REEL7 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 417 |
|
$2.0600 / $3.9200 | Buy Now |
|
DISTI #
505-AD8030ARJZ-REEL7CT-ND
|
DigiKey | IC OPAMP GP 2 CIRCUIT SOT23-8 Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
2844 In Stock |
|
$1.9500 / $5.3400 | Buy Now |
|
DISTI #
584-AD8030ARJZ-R7
|
Mouser Electronics | High Speed Operational Amplifiers Low Power R-R I/O Amp RoHS: Compliant | 9659 |
|
$2.0200 / $3.9200 | Buy Now |
|
|
Analog Devices Inc | Low Power R-R I/O Amp Min Qty: 3000 Package Multiple: 3000 | 3000 |
|
$1.9500 / $5.3400 | Buy Now |
|
|
Quest Components | OPERATIONAL AMPLIFIER, 2 FUNC, 6000UV OFFSET-MAX, BIPOLAR, PDSO8 | 2055 |
|
$1.6620 / $3.3240 | Buy Now |
|
|
Quest Components | OPERATIONAL AMPLIFIER, 2 FUNC, 6000UV OFFSET-MAX, BIPOLAR, PDSO8 | 19 |
|
$1.9800 / $3.9600 | Buy Now |
|
DISTI #
AD8030ARJZ-R7
|
Richardson RFPD | AMPLIFIER - OP AMPS RoHS: Compliant Min Qty: 3000 | 0 |
|
$2.0400 | Buy Now |
|
|
LCSC | Dual 700nA 63V/us 125MHz Rail-to-rail input Rail-to-rail output 6mV SOT-23-8 Operational Amplifier ROHS | 39 |
|
$2.1342 / $2.4240 | Buy Now |
|
|
Vyrian | Amplifiers | 4509 |
|
RFQ | |
|
|
Win Source Electronics | Op Amp Dual High Speed Amplifier R-R I/O ±6V/12V Automotive 8-Pin SOT-23 T/R / IC OPAMP GP 125MHZ RRO SOT23-8 | 8720 |
|
$1.6667 / $2.1527 | Buy Now |
Part Details for AD8030ARJZ-REEL7
AD8030ARJZ-REEL7 CAD Models
AD8030ARJZ-REEL7 Part Data Attributes
|
|
AD8030ARJZ-REEL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD8030ARJZ-REEL7
Analog Devices Inc
Low-Power High-Speed Rail-to-Rail Input/Output Op Amplifier
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | ROHS COMPLIANT, MO-178BA, SOT-23, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | RJ-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Amplifier Type | OPERATIONAL AMPLIFIER | |
| Architecture | VOLTAGE-FEEDBACK | |
| Bias Current-Max (IIB) @25C | 2.8 µA | |
| Common-mode Reject Ratio-Nom | 90 dB | |
| Frequency Compensation | YES | |
| Input Offset Voltage-Max | 6000 µV | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 2.9 mm | |
| Low-Bias | NO | |
| Low-Offset | NO | |
| Micropower | NO | |
| Moisture Sensitivity Level | 1 | |
| Neg Supply Voltage Limit-Max | -6.3 V | |
| Neg Supply Voltage-Nom (Vsup) | -5 V | |
| Number of Functions | 2 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSSOP8,.1 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Packing Method | TR, 7 INCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power | NO | |
| Programmable Power | NO | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.45 mm | |
| Slew Rate-Nom | 63 V/us | |
| Supply Current-Max | 3 mA | |
| Supply Voltage Limit-Max | 6.3 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Voltage Gain-Min | 1580 | |
| Wideband | YES | |
| Width | 1.6 mm |
