AD7541AKR Information
AD7541AKR by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD7541AKR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | 646 |
|
RFQ | ||
|
|
Quest Components | IC,D/A CONVERTER,SINGLE,12-BIT,CMOS,SOP,18PIN | 190 |
|
$31.7766 / $41.0020 | Buy Now |
|
|
Rochester Electronics | D/A Converter, 1 Func, Parallel, Word Input Loading, 0.6us Settling Time, PDSO18 RoHS: Not Compliant Status: Obsolete Min Qty: 1 | 25491 |
|
$8.2000 / $10.2500 | Buy Now |
|
|
ComSIT USA | Electronic Component RoHS: Not Compliant |
|
|
RFQ | |
|
|
Win Source Electronics | CMOS 12-Bit Monolithic Multiplying DAC | IC DAC 12BIT A-OUT 18SOIC | 5350 |
|
$11.3733 / $17.0598 | Buy Now |
Part Details for AD7541AKR
AD7541AKR CAD Models
AD7541AKR Part Data Attributes
|
|
AD7541AKR
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD7541AKR
Analog Devices Inc
CMOS,12-Bit, Monolithic Multiplying DAC
|
| Pbfree Code | No | |
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-18 | |
| Pin Count | 18 | |
| Manufacturer Package Code | RW-18 | |
| Reach Compliance Code | unknown | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY, OFFSET BINARY | |
| Input Format | PARALLEL, WORD | |
| JESD-30 Code | R-PDSO-G18 | |
| JESD-609 Code | e0 | |
| Length | 11.55 mm | |
| Linearity Error-Max (EL) | 0.0122% | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 12 | |
| Number of Functions | 1 | |
| Number of Terminals | 18 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP18,.4 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 240 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.65 mm | |
| Settling Time-Nom (tstl) | 0.6 µs | |
| Supply Current-Max | 2 mA | |
| Supply Voltage-Nom | 15 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | TIN LEAD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Width | 7.5 mm |
