Part Details for AD654JRZ-REEL by Analog Devices Inc
Results Overview of AD654JRZ-REEL by Analog Devices Inc
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Aerospace and Defense
AD654JRZ-REEL Information
AD654JRZ-REEL by Analog Devices Inc is an Analog Special Function Converter.
Analog Special Function Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD654JRZ-REEL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
53AK9734
|
Newark | V/F Converter, 0Hz To 500Khz, 0.2%, Frequency:500Khz, Full Scale Range:0Hz To 500Khz, Linearity %:0.2%, Supply Voltage Range:4.5V To 36V, ± 5V To ± 18V, Digital Ic Case:Nsoic, No. Of Pins:8Pins, Product Range:-, Msl:Msl 1 - Unlimitedrohs Compliant: Yes |Analog Devices AD654JRZ-REEL RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 2944 |
|
$10.0000 / $11.9300 | Buy Now |
|
DISTI #
AD654JRZ-REELCT-ND
|
DigiKey | IC V/F CONV 500KHZ 8SOIC Min Qty: 1 Lead time: 13 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
3841 In Stock |
|
$9.4000 / $17.1800 | Buy Now |
|
DISTI #
584-AD654JRZ-R
|
Mouser Electronics | Voltage to Frequency & Frequency to Voltage IC - LOW COST V/F CONV. RoHS: Compliant | 3932 |
|
$9.3900 / $14.1300 | Buy Now |
|
|
Analog Devices Inc | IC - LOW COST V/F CONV. Min Qty: 1 Package Multiple: 2500 | 769 |
|
$7.1500 / $17.1800 | Buy Now |
|
|
ComSIT USA | LOW COST MONOLITHIC VOLTAGE-TO-FREQUENCY CONVERTER Voltage to Frequency Converter, 1 Func, 0.5MHz, Bipolar, PDSO8 ECCN: EAR99 RoHS: Compliant |
|
|
RFQ | |
|
|
Win Source Electronics | Low Cost Monolithic Voltage-to-Frequency Converter | IC V-F CONVERTER MONO 8-SOIC | 5680 |
|
$5.4659 / $7.0601 | Buy Now |
Part Details for AD654JRZ-REEL
AD654JRZ-REEL CAD Models
AD654JRZ-REEL Part Data Attributes
|
|
AD654JRZ-REEL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD654JRZ-REEL
Analog Devices Inc
Low Cost Monolithic Voltage-to-Frequency Converter
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | R-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Converter Type | VOLTAGE TO FREQUENCY CONVERTER | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Linearity Error-Max (EL) | 0.4% | |
| Moisture Sensitivity Level | 1 | |
| Negative Input Voltage-Max | -5 V | |
| Negative Supply Voltage-Nom | -5 V | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Frequency-Max | 0.5 MHz | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Positive Input Voltage-Max | 1 V | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Current-Max | 3 mA | |
| Supply Voltage-Max | 36 V | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
Alternate Parts for AD654JRZ-REEL
This table gives cross-reference parts and alternative options found for AD654JRZ-REEL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AD654JRZ-REEL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| AD654JR | Analog Devices Inc | Check for Price | Low Cost Monolithic Voltage-to-Frequency Converter | AD654JRZ-REEL vs AD654JR |
AD654JRZ-REEL Frequently Asked Questions (FAQ)
-
The recommended power-up sequence is to apply the analog supply voltage (VCC) before the digital supply voltage (VDD). This ensures that the internal analog circuitry is powered up before the digital circuitry.
-
The AD654JRZ-REEL is specified to operate from -40°C to 125°C. Ensure that the device is properly heat-sinked and that the ambient temperature is within the specified range. Also, consider the thermal resistance of the package and the PCB layout to ensure proper heat dissipation.
-
Keep the analog and digital supply pins separate and use a star-ground configuration to minimize noise. Use a solid ground plane and keep the signal traces short and direct. Avoid running digital signals near analog signals to minimize noise coupling.
-
Handle the device by the body or use an anti-static wrist strap to prevent electrostatic discharge (ESD). Use ESD-protected workstations and follow proper ESD handling procedures to prevent damage to the device.
-
Use a 0.1 μF ceramic capacitor between the analog supply pin (VCC) and ground, and a 0.01 μF ceramic capacitor between the digital supply pin (VDD) and ground. Place the capacitors as close to the device as possible to minimize inductance.
