AD584SH Information
AD584SH by Analog Devices Inc is a Voltage Reference.
Voltage References are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for AD584SH
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
AD584SH-ND
|
DigiKey | IC VREF SERIES 0.3% TO99-8 Min Qty: 100 Lead time: 10 Weeks Container: Bulk | Temporarily Out of Stock |
|
$73.6800 | Buy Now |
|
|
Analog Devices Inc | IC - PROGRAMMABLE V REF. Package Multiple: 100 | 300 |
|
$31.3900 / $51.5600 | Buy Now |
|
|
Bristol Electronics | 1 |
|
RFQ | ||
|
|
Quest Components | IC,VOLT REFERENCE,PIN-PROGRAMMABLE,2.5V/5V/7.5V/10V,BIPOLAR,CAN,8PIN,METAL | 1 |
|
$294.0000 | Buy Now |
|
DISTI #
AD584SH
|
Richardson RFPD | VOLTAGE REFERENCE RoHS: Not Compliant Min Qty: 1 | 0 |
|
RFQ | |
|
DISTI #
SMC-AD584SH
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 873 |
|
RFQ | |
|
|
Win Source Electronics | Pin Programmable Precision Voltage Reference | IC VREF SERIES PROG TO99-8 | 1485 |
|
$36.1573 / $46.7024 | Buy Now |
Part Details for AD584SH
AD584SH CAD Models
AD584SH Part Data Attributes
|
|
AD584SH
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD584SH
Analog Devices Inc
Pin Programmable Precision Voltage Reference
|
| Pbfree Code | No | |
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | TO-99 | |
| Package Description | HERMETIC SEALED, METAL CAN, TO-99, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | H-08-1 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | ADDITIONAL PROGRAMMABLE OUTPUTS OF 7.5V, 5V, 2.5V AVAILABLE | |
| Analog IC - Other Type | THREE TERMINAL VOLTAGE REFERENCE | |
| JESD-30 Code | O-MBCY-W8 | |
| JESD-609 Code | e0 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Voltage-Max | 10.03 V | |
| Output Voltage-Min | 9.97 V | |
| Output Voltage-Nom | 10 V | |
| Package Body Material | METAL | |
| Package Code | BCY | |
| Package Equivalence Code | CAN8,.2 | |
| Package Shape | ROUND | |
| Package Style | CYLINDRICAL | |
| Qualification Status | Not Qualified | |
| Supply Current-Max (Isup) | 1 mA | |
| Supply Voltage-Max (Vsup) | 30 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 15 V | |
| Surface Mount | NO | |
| Technology | BIPOLAR | |
| Temp Coef of Voltage-Max | 30 ppm/°C | |
| Temperature Grade | MILITARY | |
| Terminal Finish | Tin/Lead (Sn/Pb) | |
| Terminal Form | WIRE | |
| Terminal Position | BOTTOM | |
| Trim/Adjustable Output | YES | |
| Voltage Tolerance-Max | 0.3% |
