AD5686BCPZ-RL7 Information
AD5686BCPZ-RL7 by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD5686BCPZ-RL7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
78AK2426
|
Newark | D/A Conv, 16Bit, Lfcsp-Ep-16, 105Deg C Rohs Compliant: Yes |Analog Devices AD5686BCPZ-RL7 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 765 |
|
$14.6000 / $23.3200 | Buy Now |
|
DISTI #
505-AD5686BCPZ-RL7CT-ND
|
DigiKey | IC DAC 16BIT V-OUT 16LFCSP Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
843 In Stock |
|
$13.9875 / $23.3200 | Buy Now |
|
DISTI #
584-AD5686BCPZ-R7
|
Mouser Electronics | Digital to Analog Converters - DAC 16-bit 4-ch SPI nanoDAC+ RoHS: Compliant | 219 |
|
$14.3800 / $23.3500 | Buy Now |
|
DISTI #
V72:2272_06210810
|
Arrow Electronics | DAC 4-CH Resistor-String 16-bit 16-Pin LFCSP EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Date Code: 2324 Container: Cut Strips | Americas - 977 |
|
$14.3500 / $17.0900 | Buy Now |
|
|
Analog Devices Inc | 16-bit 4-ch SPI nanoDAC+ Min Qty: 1 Package Multiple: 1500 | 4673 |
|
$10.6400 / $23.3200 | Buy Now |
|
DISTI #
69142337
|
Verical | DAC 4-CH Resistor-String 16-bit 16-Pin LFCSP EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 2324 | Americas - 977 |
|
$14.3500 / $16.8000 | Buy Now |
|
|
LCSC | 8us SPI 2LSB 2.7V5.5V 16Bit LFCSP-16(3x3) Digital to Analog Converters (DAC) ROHS | 10 |
|
$26.8059 / $28.2681 | Buy Now |
Part Details for AD5686BCPZ-RL7
AD5686BCPZ-RL7 CAD Models
AD5686BCPZ-RL7 Part Data Attributes
|
|
AD5686BCPZ-RL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD5686BCPZ-RL7
Analog Devices Inc
Quad, 16-Bit nanoDAC+ with SPI Interface
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFN | |
| Package Description | LFCSP-16 | |
| Pin Count | 16 | |
| Manufacturer Package Code | CP-16-22 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Output Voltage-Max | 5.5 V | |
| Analog Output Voltage-Min | ||
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY | |
| Input Format | SERIAL | |
| JESD-30 Code | S-XQCC-N16 | |
| JESD-609 Code | e3 | |
| Length | 3 mm | |
| Linearity Error-Max (EL) | 0.0046% | |
| Moisture Sensitivity Level | 3 | |
| Number of Bits | 16 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC16,.12SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Settling Time-Max | 8 µs | |
| Settling Time-Nom (tstl) | 5 µs | |
| Supply Current-Max | 0.7 mA | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 3 mm |
