Part Details for AD5667BCPZ-REEL7 by Analog Devices Inc
Results Overview of AD5667BCPZ-REEL7 by Analog Devices Inc
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (7 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
AD5667BCPZ-REEL7 Information
AD5667BCPZ-REEL7 by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD5667BCPZ-REEL7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
AD5667BCPZ-REEL7CT-ND
|
DigiKey | IC DAC 16BIT V-OUT 10LFCSP Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) | Temporarily Out of Stock |
|
$6.3750 / $13.5500 | Buy Now |
|
DISTI #
584-AD5667BCPZ-R7
|
Mouser Electronics | Digital to Analog Converters - DAC Dual 2.7-5.5V 16bit I2C DAC with LDAC RoHS: Compliant | 0 |
|
$6.3700 | Order Now |
|
|
Analog Devices Inc | Dual 2.7-5.5V 16bit I2C DAC wi Min Qty: 1500 Package Multiple: 1500 | 0 |
|
$4.8500 / $13.5500 | Buy Now |
|
DISTI #
88084576
|
Verical | DAC 2-CH Resistor-String 16-bit 10-Pin LFCSP EP T/R RoHS: Compliant Min Qty: 500 Package Multiple: 500 | Americas - 500 |
|
$13.7793 | Buy Now |
|
DISTI #
AD5667BCPZ-R7
|
Richardson RFPD | CONVERTER - DAC RoHS: Compliant Min Qty: 1500 | 0 |
|
$6.6700 | Buy Now |
Part Details for AD5667BCPZ-REEL7
AD5667BCPZ-REEL7 CAD Models
AD5667BCPZ-REEL7 Part Data Attributes
|
|
AD5667BCPZ-REEL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD5667BCPZ-REEL7
Analog Devices Inc
Dual, 16-Bit nanoDAC® with I2C® Interface
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | 3 X 3 MM, LEAD FREE, LFCSP-10 | |
| Pin Count | 10 | |
| Manufacturer Package Code | CP-10-9 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Output Voltage-Max | 5.5 V | |
| Analog Output Voltage-Min | ||
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY | |
| Input Format | SERIAL | |
| JESD-30 Code | S-XDSO-N10 | |
| JESD-609 Code | e3 | |
| Length | 3 mm | |
| Linearity Error-Max (EL) | 0.0183% | |
| Moisture Sensitivity Level | 3 | |
| Number of Bits | 16 | |
| Number of Functions | 1 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC10,.12,20 | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Settling Time-Max | 7 µs | |
| Settling Time-Nom (tstl) | 4 µs | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Width | 3 mm |
Alternate Parts for AD5667BCPZ-REEL7
This table gives cross-reference parts and alternative options found for AD5667BCPZ-REEL7. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AD5667BCPZ-REEL7, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| AD5667RBCPZ-R2 | Analog Devices Inc | $8.3377 | Dual, 16-Bit nanoDAC® with 5 ppm/°C On-Chip Reference, I2C® Interface | AD5667BCPZ-REEL7 vs AD5667RBCPZ-R2 |
| AD5667RBRMZ-2 | Analog Devices Inc | $8.4150 | Dual, 16-Bit nanoDAC® with 5 ppm/°C On-Chip Reference, I2C® Interface | AD5667BCPZ-REEL7 vs AD5667RBRMZ-2 |
| AD5667BRMZ-REEL7 | Analog Devices Inc | $9.0318 | Dual, 16-Bit nanoDAC® with I2C® Interface | AD5667BCPZ-REEL7 vs AD5667BRMZ-REEL7 |
| AD5667BCPZ-250RL7 | Analog Devices Inc | Check for Price | IC SERIAL INPUT LOADING, 4 us SETTLING TIME, 16-BIT DAC, DSO10, 3 X 3 MM, LEAD FREE, LFCSP-10, Digital to Analog Converter | AD5667BCPZ-REEL7 vs AD5667BCPZ-250RL7 |
| AD5667BCPZ-R2 | Analog Devices Inc | Check for Price | Dual, 16-Bit nanoDAC® with I2C® Interface | AD5667BCPZ-REEL7 vs AD5667BCPZ-R2 |
| AD5667RBRMZ-2REEL7 | Analog Devices Inc | Check for Price | Dual, 16-Bit nanoDAC® with 5 ppm/°C On-Chip Reference, I2C® Interface | AD5667BCPZ-REEL7 vs AD5667RBRMZ-2REEL7 |
| AD5667RBCPZ-REEL7 | Analog Devices Inc | Check for Price | Dual, 16-Bit nanoDAC® with 5 ppm/°C On-Chip Reference, I2C® Interface | AD5667BCPZ-REEL7 vs AD5667RBCPZ-REEL7 |
AD5667BCPZ-REEL7 Frequently Asked Questions (FAQ)
-
The recommended power-up sequence for the AD5667 is to power up VDD first, followed by AVCC, and then the digital interface (SCL and SDA). This ensures that the internal voltage regulators are properly initialized.
-
To ensure accurate voltage output from the AD5667, it is essential to use a high-precision voltage reference, such as the ADR431 or ADR452, and to follow proper PCB layout and design guidelines to minimize noise and thermal effects.
-
The AD5667's output can drive up to 1 μF of capacitance. However, it is recommended to limit the capacitance to 100 nF or less to ensure stability and prevent oscillations.
-
To implement a voltage clamp or limit on the AD5667's output, you can use an external voltage clamp circuit, such as a zener diode or a voltage regulator, or use the AD5667's internal voltage limit feature by programming the VLIMIT register.
-
The recommended clock frequency for the AD5667's I2C interface is up to 400 kHz. However, the device can operate at higher clock frequencies, up to 1 MHz, but with reduced noise immunity and increased power consumption.
