A5975ADTR Information
A5975ADTR by STMicroelectronics is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for A5975ADTR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86T8910
|
Newark | Dc-Dc Converters |Stmicroelectronics A5975ADTR RoHS: Not Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now | |
|
DISTI #
497-11425-1-ND
|
DigiKey | IC REG BUCK ADJ 2.5A 8HSOP Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
4616 In Stock |
|
$1.5200 / $3.1300 | Buy Now |
|
DISTI #
A5975ADTR
|
Avnet Americas | Conv DC-DC Single Step Down 4V to 36V 8-Pin HSOP EP T/R - Tape and Reel (Alt: A5975ADTR) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$1.4744 / $1.5392 | Buy Now |
|
DISTI #
511-A5975ADTR
|
Mouser Electronics | Switching Voltage Regulators Up to 2.5A Step-Down Auto REG 4V to 36V RoHS: Compliant | 0 |
|
$1.5200 / $3.1300 | Order Now |
|
|
STMicroelectronics | Up to 2.5 A step down switching regulator for automotive applications RoHS: Compliant Min Qty: 1 | 0 |
|
$1.7400 / $3.0700 | Buy Now |
|
DISTI #
A5975ADTR
|
Avnet Silica | Conv DCDC Single Step Down 4V to 36V 8Pin HSOP EP TR (Alt: A5975ADTR) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days | Silica - 5000 |
|
Buy Now | |
|
DISTI #
A5975ADTR
|
EBV Elektronik | Conv DCDC Single Step Down 4V to 36V 8Pin HSOP EP TR (Alt: A5975ADTR) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Win Source Electronics | IC REG BUCK ADJ 2.5A 8SOIC | 12501 |
|
$1.6496 / $2.4744 | Buy Now |
Part Details for A5975ADTR
A5975ADTR CAD Models
A5975ADTR Part Data Attributes
|
|
A5975ADTR
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
A5975ADTR
STMicroelectronics
Up to 2.5 A step down switching regulator for automotive applications
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | SOIC | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Additional Feature | OUTPUT VOLTAGE ADJUSTABLE FROM 1.235 V TO 35 V | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | VOLTAGE-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 36 V | |
| Input Voltage-Min | 4 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 4.1 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HLSOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.7 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 575 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
