A4933KJPTR-T Information
A4933KJPTR-T by Allegro MicroSystems LLC is a Motion Control Electronic.
Motion Control Electronics are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for A4933KJPTR-T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
620-A4933KJPTR-TCT-ND
|
DigiKey | IC MOTOR DRIVER 3V-5.5V 48LQFP Min Qty: 1 Lead time: 15 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
14930 In Stock |
|
$3.1354 / $5.6200 | Buy Now |
|
DISTI #
250-A4933KJPTR-T
|
Mouser Electronics | Motor / Motion / Ignition Controllers & Drivers AUTOMOTIVE 3-PHASE MOSFET PRE-DRIVER RoHS: Compliant | 7066 |
|
$3.1200 / $5.6200 | Buy Now |
|
DISTI #
85963770
|
Verical | 3-Phase Motor Driver Automotive AEC-Q100 48-Pin LQFP EP T/R RoHS: Compliant Min Qty: 98 Package Multiple: 1 Date Code: 2201 | Americas - 4500 |
|
$3.0750 / $3.8375 | Buy Now |
|
DISTI #
85963345
|
Verical | 3-Phase Motor Driver Automotive AEC-Q100 48-Pin LQFP EP T/R RoHS: Compliant Min Qty: 98 Package Multiple: 1 Date Code: 2301 | Americas - 1481 |
|
$3.0750 / $3.8375 | Buy Now |
|
|
Rochester Electronics | 3 Phase MOSFET Pre-Driver RoHS: Compliant Status: Active Min Qty: 1 | 5981 |
|
$2.4600 / $3.0700 | Buy Now |
|
DISTI #
A4933KJPTR-T
|
Avnet Silica | 3Phase Motor Driver 48Pin LQFP EP TR (Alt: A4933KJPTR-T) RoHS: Compliant Min Qty: 9000 Package Multiple: 9000 Lead time: 20 Weeks, 0 Days | Silica - 0 |
|
Buy Now |
Part Details for A4933KJPTR-T
A4933KJPTR-T CAD Models
A4933KJPTR-T Part Data Attributes
|
|
A4933KJPTR-T
Allegro MicroSystems LLC
Buy Now
Datasheet
|
Compare Parts:
A4933KJPTR-T
Allegro MicroSystems LLC
Brushless DC Motor Controller, PQFP48, LEAD FREE, MS-026BBCHD, LQFP-48
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ALLEGRO MICROSYSTEMS LLC | |
| Part Package Code | QFP | |
| Package Description | LEAD FREE, MS-026BBCHD, LQFP-48 | |
| Pin Count | 48 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Allegro Microsystems | |
| Additional Feature | ALSO REQUIRE 5.5V TO 50V | |
| Analog IC - Other Type | BRUSHLESS DC MOTOR CONTROLLER | |
| JESD-30 Code | S-PQFP-G48 | |
| JESD-609 Code | e3 | |
| Length | 7 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Functions | 1 | |
| Number of Terminals | 48 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HLFQFP | |
| Package Equivalence Code | QFP48,.35SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, HEAT SINK/SLUG, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.6 mm | |
| Supply Current-Max (Isup) | 6 mA | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Width | 7 mm |
