WM8940CGEFL/V Information
WM8940CGEFL/V by Cirrus Logic is a Codec.
Codecs are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for WM8940CGEFL/V
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
WM8940CGEFL/V
|
Avnet Americas | Audio Codec 1ADC /1 DAC 24-Bit 24-Pin QFN - Trays (Alt: WM8940CGEFL/V) RoHS: Compliant Min Qty: 490 Package Multiple: 490 Lead time: 111 Weeks, 0 Days Container: Tray | 0 |
|
RFQ |
Part Details for WM8940CGEFL/V
WM8940CGEFL/V CAD Models
WM8940CGEFL/V Part Data Attributes
|
|
WM8940CGEFL/V
Cirrus Logic
Buy Now
Datasheet
|
Compare Parts:
WM8940CGEFL/V
Cirrus Logic
PCM Codec, A/MU-Law, 1-Func, CMOS, PQCC24, 4 X 4 MM, 0.90 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, MO-220VGGD-8, QFN-24
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | CIRRUS LOGIC INC | |
| Package Description | HVQCCN, | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | Cirrus Logic | |
| Companding Law | A/MU-LAW | |
| Filter | YES | |
| JESD-30 Code | S-PQCC-N24 | |
| Length | 4 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 24 | |
| Operating Mode | SYNCHRONOUS | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -25 °C | |
| Output | VOLTAGE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC24,.16SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.9 mm | |
| Supply Voltage-Nom | 1.8 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Telecom IC Type | PCM CODEC | |
| Temperature Grade | OTHER | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 4 mm |
