TXB0304RSVR Information
TXB0304RSVR by Texas Instruments is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for TXB0304RSVR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-29681-1-ND
|
DigiKey | IC TRANSLTR BIDIRECTIONAL 16UQFN Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
14827 In Stock |
|
$0.4108 / $0.9300 | Buy Now |
|
DISTI #
595-TXB0304RSVR
|
Mouser Electronics | Translation - Voltage Levels 4B BIDIREC AUTO-DIR SENSING TRANSLATOR RoHS: Compliant | 3641 |
|
$0.4150 / $0.9300 | Buy Now |
|
|
Win Source Electronics | 4-BIT BIDIRECTIONAL VOLTAGE-LEVEL TRANSLATOR WITH AUTOMATIC DIRECTION SENSING | IC TRNSLTR BIDIRECTIONAL 16UQFN | 9320 |
|
$0.4230 / $0.6343 | Buy Now |
Part Details for TXB0304RSVR
TXB0304RSVR CAD Models
TXB0304RSVR Part Data Attributes
|
|
TXB0304RSVR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TXB0304RSVR
Texas Instruments
4-bit Bidirectional Auto-direction Sensing Translator with Fully Symmetric 0.9V to 3.6V Range 16-UQFN -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QFN | |
| Package Description | GREEN, PLASTIC, MO-288UFHE, UQFN-16 | |
| Pin Count | 16 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Interface IC Type | INTERFACE CIRCUIT | |
| JESD-30 Code | R-PQCC-N16 | |
| JESD-609 Code | e4 | |
| Length | 2.6 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 4 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | 3-STATE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VQCCN | |
| Package Equivalence Code | LCC16,.07X.1,16 | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.55 mm | |
| Supply Current-Max | 0.01 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 0.9 V | |
| Supply Voltage1-Max | 3.6 V | |
| Supply Voltage1-Min | 0.9 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.4 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.8 mm |
Alternate Parts for TXB0304RSVR
This table gives cross-reference parts and alternative options found for TXB0304RSVR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TXB0304RSVR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TXB0304RUTR | Texas Instruments | $1.0045 | 4-bit Bidirectional Auto-direction Sensing Translator with Fully Symmetric 0.9V to 3.6V Range 12-UQFN -40 to 85 | TXB0304RSVR vs TXB0304RUTR |
TXB0304RSVR Frequently Asked Questions (FAQ)
-
A good PCB layout for the TXB0304RSVR involves keeping the input and output traces short and wide, using a solid ground plane, and placing the device close to the power source. Additionally, it's recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane.
-
To ensure proper powering and decoupling of the TXB0304RSVR, use a high-quality power source with low noise and ripple, and add decoupling capacitors (e.g., 10uF and 100nF) close to the device. Also, ensure that the power and ground pins are connected to a solid power plane and ground plane, respectively.
-
The TXB0304RSVR has a maximum junction temperature of 150°C. To ensure reliable operation, keep the device within a temperature range of -40°C to 125°C. Use a heat sink or thermal pad if the device is expected to operate in high-temperature environments or under high-power conditions.
-
To troubleshoot issues with the TXB0304RSVR, start by checking the power supply and decoupling, then verify the input and output signals using an oscilloscope. Check for any signs of overheating, and ensure that the device is properly soldered and connected. Consult the datasheet and application notes for specific troubleshooting guidelines.
-
Yes, the TXB0304RSVR is a high-frequency device and requires proper EMI/EMC design considerations. Use a shielded enclosure, keep the device away from other high-frequency components, and use EMI filters or shielding on the input and output lines if necessary.
