TLE42764GV50ATMA1 by: Infineon Technologies AG

Fixed Positive LDO Regulator, 5V, 0.5V Dropout, PSSO5, GREEN, PLASTIC, TO-263, 5 PIN

Part Details for TLE42764GV50ATMA1 by Infineon Technologies AG

Results Overview of TLE42764GV50ATMA1 by Infineon Technologies AG

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Automotive

TLE42764GV50ATMA1 Information

TLE42764GV50ATMA1 by Infineon Technologies AG is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for TLE42764GV50ATMA1

Part # Distributor Description Stock Price Buy
DISTI # 28AC4039
Newark Linear Voltage Regulator Rohs Compliant: Yes |Infineon TLE42764GV50ATMA1 RoHS: Compliant Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Reel 14000
  • 1 $1.1600
$1.1600 Buy Now
DISTI # TLE42764GV50ATMA1CT-ND
DigiKey IC REG LINEAR 5V 400MA TO263-5 Min Qty: 1 Lead time: 13 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 2759
In Stock
  • 1 $2.3800
  • 10 $1.7650
  • 25 $1.6116
  • 100 $1.4428
  • 250 $1.3624
  • 500 $1.3140
  • 1,000 $1.0412
$1.0412 / $2.3800 Buy Now
DISTI # TLE42764GV50ATMA1
Avnet Americas Fixed LDO Voltage Regulator, 5.5V to 40V, 250mV Dropout, 5Vout, 400mAout, TO-263-5 - Tape and Reel (Alt: TLE42764GV50ATMA1) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 53 Weeks, 1 Days Container: Reel 14000
  • 1,000 $1.0556
  • 2,000 $1.0377
  • 4,000 $1.0200
  • 6,000 $1.0021
  • 8,000 $0.9842
$0.9842 / $1.0556 Buy Now
DISTI # 726-TLE42764GV50ATMA
Mouser Electronics LDO Voltage Regulators LINEAR VOLTAGE REGULATOR RoHS: Compliant 4957
  • 1 $2.3800
  • 10 $1.7700
  • 25 $1.6200
  • 100 $1.4500
  • 250 $1.3700
  • 500 $1.3200
  • 1,000 $1.1500
  • 2,000 $1.1200
  • 5,000 $1.1100
$1.1100 / $2.3800 Buy Now
DISTI # E02:0323_02013545
Arrow Electronics LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 1000 Package Multiple: 1000 Lead time: 13 Weeks Europe - 1000
  • 1,000 $1.2231
$1.2231 Buy Now
DISTI # V36:1790_06383173
Arrow Electronics LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 1000 Package Multiple: 1000 Lead time: 13 Weeks Date Code: 2421 Americas - 1000
  • 1,000 $1.0695
$1.0695 Buy Now
DISTI # V72:2272_06383173
Arrow Electronics LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Date Code: 2235 Container: Cut Strips Americas - 250
  • 1 $1.2790
  • 10 $1.2580
  • 25 $1.2380
  • 100 $1.2180
  • 250 $1.1980
$1.1980 / $1.2790 Buy Now
DISTI # 33723462
Verical LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 1000 Package Multiple: 1000 Americas - 1000
  • 1,000 $0.9854
$0.9854 Buy Now
DISTI # 69266709
Verical LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 32 Package Multiple: 1 Date Code: 2318 Americas - 800
  • 32 $1.2200
  • 50 $1.2000
  • 100 $1.1800
  • 500 $1.1600
$1.1600 / $1.2200 Buy Now
DISTI # 87802033
Verical LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 199 Package Multiple: 1 Date Code: 2201 Americas - 356
  • 199 $1.8875
  • 500 $1.7000
  • 1,000 $1.5625
  • 10,000 $1.4000
  • 100,000 $1.1713
$1.1713 / $1.8875 Buy Now
DISTI # 88046134
Verical LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 6-Pin(5+Tab) TO-263 T/R Min Qty: 199 Package Multiple: 1 Date Code: 1901 Americas - 255
  • 199 $1.8875
  • 500 $1.7000
  • 1,000 $1.5625
  • 10,000 $1.4000
  • 100,000 $1.1713
$1.1713 / $1.8875 Buy Now
Rochester Electronics TLE42764 - Linear Voltage Regulator RoHS: Compliant Status: Not Recommended for New Designs Min Qty: 1 611
  • 100 $1.5100
  • 500 $1.3600
  • 1,000 $1.2500
  • 10,000 $1.1200
  • 100,000 $0.9370
$0.9370 / $1.5100 Buy Now
DISTI # TLE42764GV50ATMA1
TME IC: voltage regulator, LDO,linear,fixed, 5V, 0.4A, PG-TO263-5, SMD Min Qty: 1 0
  • 1 $1.8100
  • 10 $1.5400
  • 100 $1.3900
  • 250 $1.2900
  • 500 $1.2500
  • 1,000 $1.2000
$1.2000 / $1.8100 RFQ
DISTI # SP000636154
EBV Elektronik Fixed LDO Voltage Regulator 55V to 40V 250mV Dropout 5Vout 400mAout TO2635 (Alt: SP000636154) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 14 Weeks, 0 Days EBV - 0
Buy Now
LCSC TO-263-5 Voltage Regulators - Linear Low Drop Out (LDO) Regulators ROHS 50
  • 1 $1.6400
  • 10 $1.6038
  • 30 $1.5796
  • 100 $1.5540
$1.5540 / $1.6400 Buy Now

Part Details for TLE42764GV50ATMA1

TLE42764GV50ATMA1 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

TLE42764GV50ATMA1 Part Data Attributes

Parametric Data
TLE42764GV50ATMA1 Infineon Technologies AG
Buy Now Datasheet
Compare Parts:
TLE42764GV50ATMA1 Infineon Technologies AG Fixed Positive LDO Regulator, 5V, 0.5V Dropout, PSSO5, GREEN, PLASTIC, TO-263, 5 PIN
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Not Recommended
Ihs Manufacturer INFINEON TECHNOLOGIES AG
Part Package Code D2PAK
Package Description TO-263, 5 PIN
Pin Count 4
Reach Compliance Code not_compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 53 Weeks, 1 Day
Samacsys Manufacturer Infineon
Adjustability FIXED
Dropout Voltage1-Max 0.5 V
Dropout Voltage1-Nom 0.25 V
Input Voltage Absolute-Max 45 V
Input Voltage-Max 40 V
Input Voltage-Min 5.5 V
JESD-30 Code R-PSSO-G5
JESD-609 Code e3
Length 10 mm
Line Regulation-Max 0.025%
Load Regulation-Max 0.035%
Moisture Sensitivity Level 1
Number of Functions 1
Number of Outputs 1
Number of Terminals 5
Operating Temperature TJ-Max 150 °C
Operating Temperature TJ-Min -40 °C
Output Current1-Max 0.4 A
Output Voltage1-Max 5.1 V
Output Voltage1-Min 4.9 V
Output Voltage1-Nom 5 V
Package Body Material PLASTIC/EPOXY
Package Code TO-263
Package Equivalence Code SMSIP5H,.6,67TB
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Qualification Status Not Qualified
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Screening Level AEC-Q100
Seated Height-Max 4.4 mm
Surface Mount YES
Terminal Finish Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 1.7 mm
Terminal Position SINGLE
Voltage Tolerance-Max 2%
Width 9.25 mm
