TLE42744EV50XUMA1 Information
TLE42744EV50XUMA1 by Infineon Technologies AG is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TLE42744EV50XUMA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
25AK1412
|
Newark | Ldo, Fixed, 5V, 0.4A, -40 To 150Deg C Rohs Compliant: Yes |Infineon TLE42744EV50XUMA1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 2327 |
|
$0.6320 | Buy Now |
|
DISTI #
448-TLE42744EV50XUMA1CT-ND
|
DigiKey | IC REG LIN 5V 400MA PG-SSOP-14-2 Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
8823 In Stock |
|
$0.7268 / $1.6200 | Buy Now |
|
DISTI #
TLE42744EV50XUMA1
|
Avnet Americas | LDO Voltage Regulator, Fixed, 5.5 V to 40 V, 250 mV Drop, 5 V/400 mA, SSOP-EP, 14-Pin - Tape and Reel (Alt: TLE42744EV50XUMA1) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.8082 | Buy Now |
|
DISTI #
726-TLE42744EV50XUMA
|
Mouser Electronics | LDO Voltage Regulators Low Dropout Linear Voltage Regulator RoHS: Compliant | 22121 |
|
$0.7260 / $1.6200 | Buy Now |
|
DISTI #
66413449
|
Verical | LDO Regulator Pos 5V 0.4A Automotive AEC-Q100 14-Pin SSOP T/R RoHS: Compliant Min Qty: 45 Package Multiple: 1 | Americas - 2390 |
|
$0.7900 / $1.5500 | Buy Now |
|
DISTI #
SP000540120
|
EBV Elektronik | LDO Voltage Regulator Fixed 55 V to 40 V 250 mV Drop 5 V400 mA SSOPEP 14Pin (Alt: SP000540120) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 14 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for TLE42744EV50XUMA1
TLE42744EV50XUMA1 CAD Models
TLE42744EV50XUMA1 Part Data Attributes
|
|
TLE42744EV50XUMA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
TLE42744EV50XUMA1
Infineon Technologies AG
Fixed Positive LDO Regulator, 5V, 0.5V Dropout, PDSO14, GREEN, PLASTIC, SSOP-14
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Package Description | SSOP-14 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 13 Weeks | |
| Samacsys Manufacturer | Infineon | |
| Dropout Voltage1-Max | 0.5 V | |
| Input Voltage-Max | 40 V | |
| Input Voltage-Min | 5.5 V | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 14 | |
| Operating Temperature TJ-Max | 150 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Output Current1-Max | 1.1 A | |
| Output Voltage1-Max | 5.1 V | |
| Output Voltage1-Min | 4.9 V | |
| Output Voltage1-Nom | 5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HLSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE, SHRINK PITCH | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.7 mm | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Voltage Tolerance-Max | 2% | |
| Width | 3.9 mm |
TLE42744EV50XUMA1 Frequently Asked Questions (FAQ)
-
A good PCB layout for optimal thermal performance involves placing the device near a thermal pad or a heat sink, using thermal vias to dissipate heat, and keeping the surrounding area clear of other components.
-
To ensure EMC, use a shielded cable, keep the device away from high-frequency sources, and use a common-mode choke or ferrite bead to filter out electromagnetic interference.
-
The recommended input capacitor value is 10uF to 22uF, and a low-ESR ceramic capacitor (e.g., X5R or X7R) is recommended to minimize voltage ripple and ensure stable operation.
-
Use a voltage supervisor or a power-on reset circuit to detect and respond to overvoltage and undervoltage conditions, and consider adding overvoltage protection (OVP) and undervoltage protection (UVP) circuits to prevent damage to the device.
-
The recommended operating temperature range for the TLE42744EV50XUMA1 is -40°C to 150°C, but it's essential to consider the specific application and environmental conditions to ensure reliable operation.
