TCS34103M Information
TCS34103M by ams OSRAM Group is an Other Sensor/Transducer.
Other Sensors/Transducers are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for TCS34103M
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AK5183
|
Newark | Sensor, I2C Digital, Olga, 615Nm, Supply Voltage Min:1.7V, Supply Voltage Max:1.98V, No. Of Pins:6Pins, Operating Temperature Min:-30°C, Operating Temperature Max:85°C, Product Range:Tcs3410 Series, Sensor Output Type:I2C Digital Rohs Compliant: Yes |Ams Osram Group TCS34103M RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 870 |
|
$0.5590 / $1.0700 | Buy Now |
|
DISTI #
Q65114A1293
|
Avnet Americas | Photo Sensor LED 1.8V I2C 6-Pin OLGA - Tape and Reel (Alt: Q65114A1293) RoHS: Compliant Min Qty: 2000 Package Multiple: 1000 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$0.7500 / $0.8460 | Buy Now |
|
DISTI #
985-TCS34103M
|
Mouser Electronics | Ambient Light Sensors COLOR RoHS: Compliant | 3107 |
|
$0.9640 / $1.4800 | Buy Now |
|
DISTI #
TCS34103M
|
TTI | Ambient Light Sensors COLOR RoHS: Compliant pbFree: Pb-Free Min Qty: 2000 Package Multiple: 1000 Container: Reel | Americas - 0 |
|
$0.7500 / $0.8100 | Buy Now |
|
DISTI #
Q65114A1293
|
EBV Elektronik | Photo Sensor LED 18V I2C 6Pin OLGA (Alt: Q65114A1293) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 13 Weeks, 0 Days | EBV - 2000 |
|
Buy Now | |
|
DISTI #
HSSR-7111
|
EBV Elektronik | Photo Sensor LED 18V I2C 6Pin OLGA (Alt: HSSR-7111) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 17 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for TCS34103M
TCS34103M CAD Models
TCS34103M Part Data Attributes
|
|
TCS34103M
ams OSRAM Group
Buy Now
Datasheet
|
Compare Parts:
TCS34103M
ams OSRAM Group
Color Sensor, Open-drain, 6 Pin,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | AMS-OSRAM AG | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | ams OSRAM | |
| Body Breadth | 1 mm | |
| Body Height | 0.5 mm | |
| Body Length or Diameter | 2 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -30 °C | |
| Output | OPEN-DRAIN | |
| Output Type | DIGITAL VOLTAGE | |
| Package Shape/Style | RECTANGULAR | |
| Sensors/Transducers Type | COLOR SENSOR | |
| Supply Voltage-Max | 1.98 V | |
| Supply Voltage-Min | 1.7 V | |
| Surface Mount | YES |
TCS34103M Frequently Asked Questions (FAQ)
-
A good PCB layout for the TCS34103M involves keeping the sensor away from high-frequency components, using a solid ground plane, and minimizing the distance between the sensor and the microcontroller. A 4-layer PCB with a dedicated analog ground plane is recommended.
-
To minimize noise sensitivity, use a low-pass filter, such as a 100nF capacitor, between the VCC pin and GND. Additionally, use a shielded cable for the I2C bus and keep the sensor away from high-frequency components.
-
The recommended I2C bus speed for the TCS34103M is 400 kHz. However, the device can operate at speeds up to 1 MHz.
-
Calibration involves adjusting the gain and offset of the sensor using the built-in calibration registers. The process involves taking measurements with a known light source and adjusting the registers to match the expected values.
-
The TCS34103M can handle ambient light intensities up to 100,000 lux, making it suitable for outdoor applications.
