Part Details for TAS5162DKDR by Texas Instruments
Results Overview of TAS5162DKDR by Texas Instruments
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Audio and Video Systems
Virtual Reality (VR), Augmented Reality (AR), and Vision Systems
Entertainment and Gaming
Price & Stock for TAS5162DKDR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86288170
|
Verical | Audio Amp Speaker 1-CH Mono/2-CH Stereo 400W Class-AB 36-Pin HSSOP EP T/R RoHS: Compliant Min Qty: 26 Package Multiple: 1 Date Code: 1001 | Americas - 172 |
|
$11.7875 / $14.7375 | Buy Now |
|
|
Rochester Electronics | TAS5162 210-W Stereo Digital Amplifier Power Stage RoHS: Compliant Status: Obsolete Min Qty: 1 | 179 |
|
$9.4300 / $11.7900 | Buy Now |
|
|
Win Source Electronics | IC AMP AUDIO PWR 210W D 36SSOP | 1470 |
|
$33.6163 / $50.4238 | Buy Now |
Part Details for TAS5162DKDR
TAS5162DKDR CAD Models
TAS5162DKDR Part Data Attributes
|
|
TAS5162DKDR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TAS5162DKDR
Texas Instruments
160-W stereo, 300-W mono, 0- to 52.5-V supply, PWM input Class-D audio amplifier 36-HSSOP 0 to 70
|
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SSOP | |
| Package Description | GREEN, PLASTIC, HSSOP-36 | |
| Pin Count | 36 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.33.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | ALSO REQUIRES 50 V SUPPLY | |
| Consumer IC Type | AUDIO AMPLIFIER | |
| Harmonic Distortion | 10% | |
| JESD-30 Code | R-PDSO-G36 | |
| JESD-609 Code | e4 | |
| Length | 15.9 mm | |
| Moisture Sensitivity Level | 4 | |
| Noise Figure-Nom | 112 dB | |
| Number of Channels | 2 | |
| Number of Functions | 1 | |
| Number of Terminals | 36 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Power-Nom | 200 W | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HSSOP | |
| Package Equivalence Code | SSOP36,.56 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 3.6 mm | |
| Supply Voltage-Max (Vsup) | 13.2 V | |
| Supply Voltage-Min (Vsup) | 10.8 V | |
| Surface Mount | YES | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 11 mm |
TAS5162DKDR Frequently Asked Questions (FAQ)
-
A good PCB layout for the TAS5162DKDR involves keeping the power stage components (e.g., FETs, inductors, and capacitors) close together, using a solid ground plane, and minimizing the length of the high-current paths. TI provides a recommended PCB layout in the datasheet and application notes.
-
Optimizing the compensation network involves selecting the right values for the compensation components (R, C, and L) to ensure stability and desired transient response. TI provides a compensation design tool and guidelines in the datasheet and application notes to help with this process.
-
The maximum allowed voltage on the VIN pin is 18V, but it's recommended to keep it below 15V to ensure reliable operation and minimize the risk of damage.
-
The TAS5162DKDR has built-in overcurrent protection (OCP) and overvoltage protection (OVP) features. Additionally, external protection components such as fuses, TVS diodes, and voltage regulators can be used to provide extra protection against overcurrent and overvoltage conditions.
-
A good thermal management strategy involves using a heat sink, thermal interface material, and ensuring good airflow around the device. The TAS5162DKDR has a thermal pad that should be connected to a solid ground plane to help dissipate heat.
