STGF4M65DF2 Information
STGF4M65DF2 by STMicroelectronics is an IGBT.
IGBTs are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STGF4M65DF2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-16965-ND
|
DigiKey | IGBT TRENCH FS 650V 8A TO-220FP Min Qty: 1 Lead time: 15 Weeks Container: Tube |
6 In Stock |
|
$0.4006 / $1.6400 | Buy Now |
|
DISTI #
STGF4M65DF2
|
Avnet Americas | Trans IGBT Chip N 650V 8A 3-Pin TO-220FP Tube - Bulk (Alt: STGF4M65DF2) RoHS: Compliant Min Qty: 2000 Package Multiple: 1000 Lead time: 15 Weeks, 0 Days Container: Bulk | 0 |
|
$0.3502 / $0.3574 | Buy Now |
|
DISTI #
511-STGF4M65DF2
|
Mouser Electronics | IGBTs Trench gate field-stop IGBT, M series 650 V, 4 A low loss RoHS: Compliant | 2073 |
|
$0.3610 / $1.1500 | Buy Now |
|
|
STMicroelectronics | Trench gate field-stop IGBT, M series 650 V, 4 A low loss RoHS: Compliant Min Qty: 1 | 2073 |
|
$0.4900 / $1.1300 | Buy Now |
|
DISTI #
STGF4M65DF2
|
TME | Transistor: IGBT, 650V, 4A, 23W, TO220FP Min Qty: 1 | 0 |
|
$0.4860 / $0.8170 | RFQ |
|
DISTI #
STGF4M65DF2
|
IBS Electronics | STGF4M65DF2 by ST MICROELECTRONICS is a 650V, 4A IGBT with low saturation voltage, fast switching, and high efficiency, ideal for motor drives and power conversion applications. Min Qty: 1550 Package Multiple: 1 | 0 |
|
$0.4355 / $0.4615 | Buy Now |
|
DISTI #
STGF4M65DF2
|
Avnet Silica | Trans IGBT Chip N 650V 8A 3Pin TO220FP Tube (Alt: STGF4M65DF2) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 16 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | IGBT TRENCH FS 650V 8A TO220FP | 100 |
|
RFQ | |
|
DISTI #
STGF4M65DF2
|
EBV Elektronik | Trans IGBT Chip N 650V 8A 3Pin TO220FP Tube (Alt: STGF4M65DF2) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 16 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for STGF4M65DF2
STGF4M65DF2 CAD Models
STGF4M65DF2 Part Data Attributes
|
|
STGF4M65DF2
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STGF4M65DF2
STMicroelectronics
Trench gate field-stop IGBT, M series 650 V, 4 A low loss
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | TO-220FP, 3 PIN | |
| Manufacturer Package Code | TO-220FP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 15 Weeks | |
| Date Of Intro | 2016-11-23 | |
| Samacsys Manufacturer | STMicroelectronics | |
| Case Connection | ISOLATED | |
| Collector Current-Max (IC) | 8 A | |
| Collector-Emitter Voltage-Max | 650 V | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| Gate-Emitter Thr Voltage-Max | 7 V | |
| Gate-Emitter Voltage-Max | 20 V | |
| JEDEC-95 Code | TO-220AB | |
| JESD-30 Code | R-PSFM-T3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 175 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 23 W | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | POWER CONTROL | |
| Transistor Element Material | SILICON | |
| Turn-off Time-Nom (toff) | 296 ns | |
| Turn-on Time-Nom (ton) | 19.6 ns | |
| VCEsat-Max | 2.1 V |
