SST2907AHZGT116 Information
SST2907AHZGT116 by ROHM Semiconductor is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for SST2907AHZGT116
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
10AC9166
|
Newark | Transistor, Pnp, 60V, 0.6A, Sot-23, Transistor Polarity:Pnp, Collector Emitter Voltage Max:60V, Continuous Collector Current:600Ma, Power Dissipation:350Mw, Transistor Mounting:Surface Mount, No. Of Pins:3Pins, Product Range:- Rohs Compliant: Yes |Rohm SST2907AHZGT116 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2985 |
|
$0.0070 | Buy Now |
|
DISTI #
SST2907AHZGT116CT-ND
|
DigiKey | TRANS PNP 60V 0.6A SST3 Min Qty: 1 Lead time: 18 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
14072 In Stock |
|
$0.0185 / $0.1800 | Buy Now |
|
DISTI #
SST2907AHZGT116
|
Avnet Americas | Transistor GP BJT PNP 60V 600mA 3-Pin SOT-23 T/R - Tape and Reel (Alt: SST2907AHZGT116) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 18 Weeks, 0 Days Container: Reel | 0 |
|
RFQ | |
|
DISTI #
755-SST2907AHZGT116
|
Mouser Electronics | Bipolar Transistors - BJT PNP SOT-23 -0.6A -60V VCEO RoHS: Compliant | 0 |
|
$0.0240 / $0.1800 | Order Now |
|
DISTI #
65115937
|
Verical | Trans GP BJT PNP 60V 0.6A 350mW Automotive 3-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1516 Package Multiple: 1 Date Code: 2201 | Americas - 4880 |
|
$0.1764 | Buy Now |
|
DISTI #
69268003
|
Verical | Trans GP BJT PNP 60V 0.6A 350mW Automotive 3-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1107 Package Multiple: 1 Date Code: 2313 | Americas - 2800 |
|
$0.0384 / $0.0406 | Buy Now |
|
|
Quest Components | SMALL SIGNAL BIPOLAR TRANSISTOR, 0.6A I(C), 60V V(BR)CEO, 1-ELEMENT, PNP, SILICON | 3904 |
|
$0.0840 / $0.2800 | Buy Now |
|
DISTI #
SST2907AHZGT116
|
TME | Transistor: PNP, bipolar, 60V, 0.6A, 200/350mW, SOT23 Min Qty: 1 | 0 |
|
$0.0173 / $0.1758 | RFQ |
|
DISTI #
SST2907AHZGT116
|
IBS Electronics | BIPOLAR (BJT) TRANSISTOR PNP 60 V 600 MA 200MHZ 200 MW SURFACE MOUNT SST3 Min Qty: 6000 Package Multiple: 1 | 0 |
|
$0.0290 / $0.0315 | Buy Now |
|
DISTI #
TDSTD9185
|
Rutronik | PNP TRANSISTOR 60V 0,6A SOT23 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Container: Reel |
Stock DE - 200 Stock HK - 0 Stock US - 0 Stock SG - 0 |
|
$0.0314 / $0.0373 | Buy Now |
Part Details for SST2907AHZGT116
SST2907AHZGT116 CAD Models
SST2907AHZGT116 Part Data Attributes
|
|
SST2907AHZGT116
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
SST2907AHZGT116
ROHM Semiconductor
Small Signal Bipolar Transistor,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 18 Weeks | |
| Date Of Intro | 2016-06-29 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Collector Current-Max (IC) | 0.6 A | |
| Collector-Emitter Voltage-Max | 60 V | |
| Configuration | SINGLE | |
| DC Current Gain-Min (hFE) | 100 | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | PNP | |
| Reference Standard | AEC-Q101 | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON | |
| Transition Frequency-Nom (fT) | 200 MHz | |
| Turn-off Time-Max (toff) | 110 ns | |
| Turn-on Time-Max (ton) | 50 ns |
