SQM120P06-07L-GE3 Information
SQM120P06-07L-GE3 by Vishay Intertechnologies is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for SQM120P06-07L-GE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
28W2270
|
Newark | Mosfet, P-Channel, -60V, -120A, To-263 Package |Vishay SQM120P06-07L-GE3 RoHS: Not Compliant Min Qty: 800 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now | |
|
DISTI #
SQM120P06-07L-GE3
|
Avnet Americas | Trans MOSFET P-CH 60V 120A 3-Pin(2+Tab) D2PAK - Rail/Tube (Alt: SQM120P06-07L-GE3) RoHS: Compliant Min Qty: 800 Package Multiple: 800 Lead time: 111 Weeks, 0 Days Container: Tube | 0 |
|
RFQ | |
|
DISTI #
SQM120P06-07L-GE3
|
TTI | MOSFETs RECOMMENDED ALT SQM1 pbFree: Pb-Free Min Qty: 800 Package Multiple: 800 Container: Reel |
Americas - 55200 In Stock |
|
$1.6600 | Buy Now |
|
DISTI #
SQM120P06-07L-GE3
|
TME | Transistor: P-MOSFET, unipolar, -60V, -120A, Idm: -480A, 125W Min Qty: 1 | 359 |
|
$1.8200 / $3.2800 | Buy Now |
|
DISTI #
SQM120P06-07L-GE3
|
EBV Elektronik | Trans MOSFET PCH 60V 120A 3Pin2Tab D2PAK (Alt: SQM120P06-07L-GE3) RoHS: Compliant Min Qty: 800 Package Multiple: 800 Lead time: 41 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Vyrian | Transistors | 23174 |
|
RFQ |
Part Details for SQM120P06-07L-GE3
SQM120P06-07L-GE3 CAD Models
SQM120P06-07L-GE3 Part Data Attributes
|
|
SQM120P06-07L-GE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
SQM120P06-07L-GE3
Vishay Intertechnologies
Power Field-Effect Transistor, 120A I(D), 60V, 0.0067ohm, 1-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, TO-263AB, HALOGEN FREE AND ROHS COMPLIANT, TO-263, 3 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | HALOGEN FREE AND ROHS COMPLIANT, TO-263, 3 PIN | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Avalanche Energy Rating (Eas) | 320 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 60 V | |
| Drain Current-Max (ID) | 120 A | |
| Drain-source On Resistance-Max | 0.0067 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | TO-263AB | |
| JESD-30 Code | R-PSSO-G2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity/Channel Type | P-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 480 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | SINGLE | |
| Transistor Element Material | SILICON |
