SQJ500AEP-T1_GE3 Information
SQJ500AEP-T1_GE3 by Vishay Intertechnologies is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for SQJ500AEP-T1_GE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
79AH6757
|
Newark | N- And P-Channel 40-V (D-S) 175C Mos Rohs Compliant: No |Vishay SQJ500AEP-T1_GE3 RoHS: Not Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 12000 |
|
$0.5460 | Buy Now |
|
DISTI #
75AH9223
|
Newark | Mosfet, Complementary, 40V, 30A, 48W Rohs Compliant: Yes |Vishay SQJ500AEP-T1_GE3 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5725 |
|
$1.0700 / $1.9900 | Buy Now |
|
DISTI #
76Y1541
|
Newark | N- And P-Channel 40-V (D-S) 175C Mos |Vishay SQJ500AEP-T1_GE3 RoHS: Not Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.6640 / $0.7760 | Buy Now |
|
DISTI #
SQJ500AEP-T1_GE3
|
Avnet Americas | Trans MOSFET N/P-CH 40V/40V 30A/30A 8-Pin PowerPAK SO T/R - Tape and Reel (Alt: SQJ500AEP-T1_GE3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 20 Weeks, 0 Days Container: Reel | 12000 |
|
$0.5159 / $0.5436 | Buy Now |
|
DISTI #
78-SQJ500AEP-T1_GE3
|
Mouser Electronics | MOSFETs N and P Channel 40V AEC-Q101 Qualified RoHS: Compliant | 65292 |
|
$0.5800 / $1.6700 | Buy Now |
|
DISTI #
A03:0893_06799452
|
Arrow Electronics | Trans MOSFET N/P-CH 40V 30A Automotive AEC-Q101 5-Pin(4+Tab) PowerPAK SO T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 20 Weeks Date Code: 2316 | Asia - 3000 |
|
$0.7744 | Buy Now |
|
DISTI #
V99:2348_07799420
|
Arrow Electronics | Trans MOSFET N/P-CH 40V 30A Automotive AEC-Q101 5-Pin(4+Tab) PowerPAK SO T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 25 Weeks Date Code: 2323 | Americas - 2439 |
|
$0.5077 / $0.5131 | Buy Now |
|
DISTI #
68459849
|
Verical | Trans MOSFET N/P-CH 40V 30A Automotive AEC-Q101 5-Pin(4+Tab) PowerPAK SO T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 | Americas - 3000 |
|
$0.7744 | Buy Now |
|
DISTI #
69109458
|
Verical | Trans MOSFET N/P-CH 40V 30A Automotive AEC-Q101 5-Pin(4+Tab) PowerPAK SO T/R RoHS: Compliant Min Qty: 11 Package Multiple: 1 Date Code: 2323 | Americas - 2439 |
|
$0.5131 | Buy Now |
|
DISTI #
SQJ500AEP-T1_GE3
|
IBS Electronics | N- AND P-CHANNEL 40-V (D-S) 175C MOS ROHS COMPLIANT: NO |VISHAY SQJ500AEP-T1_GE3 Min Qty: 3000 Package Multiple: 1 | 42000 |
|
$0.4745 / $0.4875 | Buy Now |
Part Details for SQJ500AEP-T1_GE3
SQJ500AEP-T1_GE3 CAD Models
SQJ500AEP-T1_GE3 Part Data Attributes
|
|
SQJ500AEP-T1_GE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
SQJ500AEP-T1_GE3
Vishay Intertechnologies
Power Field-Effect Transistor,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | SO-8L, 4 PIN | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 20 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Avalanche Energy Rating (Eas) | 35 mJ | |
| Case Connection | DRAIN | |
| Configuration | SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 40 V | |
| Drain Current-Max (ID) | 30 A | |
| Drain-source On Resistance-Max | 0.0092 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 111 pF | |
| JESD-30 Code | R-PSSO-G4 | |
| Number of Elements | 2 | |
| Number of Terminals | 4 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL AND P-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 120 A | |
| Surface Mount | YES | |
| Terminal Form | GULL WING | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Element Material | SILICON | |
| Turn-off Time-Max (toff) | 49 ns | |
| Turn-on Time-Max (ton) | 30 ns |
SQJ500AEP-T1_GE3 Frequently Asked Questions (FAQ)
-
The recommended storage temperature for SQJ500AEP-T1_GE3 is -40°C to 125°C.
-
Yes, SQJ500AEP-T1_GE3 is RoHS compliant, meaning it meets the European Union's Restriction of Hazardous Substances directive.
-
The thermal resistance of SQJ500AEP-T1_GE3 is 2.5°C/W (junction-to-ambient) and 1.5°C/W (junction-to-case).
-
Yes, SQJ500AEP-T1_GE3 is AEC-Q101 qualified, making it suitable for use in automotive applications.
-
The recommended soldering temperature for SQJ500AEP-T1_GE3 is 260°C for 10 seconds.
