3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for SM06B-SRSS-TB(LF)(SN) by JST Manufacturing
Results Overview of SM06B-SRSS-TB(LF)(SN) by JST Manufacturing
- Distributor Offerings: (19 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
SM06B-SRSS-TB(LF)(SN) Information
SM06B-SRSS-TB(LF)(SN) by JST Manufacturing is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for SM06B-SRSS-TB(LF)(SN)
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
33P8182
|
Newark | Connector, Header, 6Pos, 1Row, 1Mm, Connector Systems:Wire-To-Board, Pitch Spacing:1Mm, No. Of Rows:1Rows, No. Of Contacts:6Contacts, Contact Termination Type:Surface Mount Right Angle, Product Range:Sr Series, Msl:Msl 1 - Unlimited Rohs Compliant: Yes |Jst/japan Solderless Terminals SM06B-SRSS-TB(LF)(SN) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 49692 |
|
$0.8020 / $1.2100 | Buy Now |
|
DISTI #
306-M06BSRSSTBLFSNPP
|
Mouser Electronics | Headers & Wire Housings SR HEADER (SMT SIDE) RoHS: Compliant | 0 |
|
$0.3470 / $0.7000 | Order Now |
|
DISTI #
E02:0323_03818144
|
Arrow Electronics | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 20 Weeks Date Code: 2335 | Europe - 144000 |
|
$0.4062 / $0.4235 | Buy Now |
|
DISTI #
E21:3489_03818144
|
Arrow Electronics | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 20 Weeks Date Code: 2318 | Europe - 1010 |
|
$0.3421 / $0.4876 | Buy Now |
|
|
Future Electronics | SH Series 6 Position 1 mm Surface Mount Right Angle Side Entry Shrouded Header RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 16 Weeks Container: Reel | 9000Reel |
|
$0.3450 | Buy Now |
|
DISTI #
JSTSM06B-SRSS-TB(LFSN).P
|
Heilind Electronics | CUT TAPE | Americas - 3024 in Stock |
|
$0.5422 / $0.6940 | Buy Now |
|
DISTI #
88074925
|
Verical | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2335 | Americas - 144000 |
|
$0.4084 / $0.4257 | Buy Now |
|
DISTI #
87615580
|
Verical | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2431 | Americas - 6000 |
|
$0.5897 | Buy Now |
|
DISTI #
88070929
|
Verical | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 215 Package Multiple: 1 Date Code: 2401 | Americas - 2638 |
|
$0.3305 / $0.3805 | Buy Now |
|
DISTI #
87332621
|
Verical | Conn Shrouded Header (4 Sides) HDR 6 POS 1mm Solder RA Side Entry SMD T/R RoHS: Compliant Min Qty: 197 Package Multiple: 1 | Americas - 979 |
|
$0.3570 | Buy Now |
Part Details for SM06B-SRSS-TB(LF)(SN)
SM06B-SRSS-TB(LF)(SN) CAD Models
SM06B-SRSS-TB(LF)(SN) Part Data Attributes
|
|
SM06B-SRSS-TB(LF)(SN)
JST Manufacturing
Buy Now
Datasheet
|
Compare Parts:
SM06B-SRSS-TB(LF)(SN)
JST Manufacturing
Board Connector, 6 Contact(s), 1 Row(s), Male, Right Angle, Surface Mount Terminal, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | J S T MFG CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.69.40.40 | |
| Samacsys Manufacturer | JST (JAPAN SOLDERLESS TERMINALS) | |
| Body Breadth | 0.114 inch | |
| Body Depth | 0.195 inch | |
| Body Length | 0.315 inch | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | TIN OVER COPPER | |
| Contact Finish Termination | TIN COPPER | |
| Contact Gender | MALE | |
| Contact Material | COPPER ALLOY | |
| Contact Pattern | RECTANGULAR | |
| Contact Resistance | 40 mΩ | |
| Contact Style | SQ PIN-SKT | |
| DIN Conformance | NO | |
| Dielectric Withstanding Voltage | 500VAC V | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulation Resistance | 100000000 Ω | |
| Insulator Color | NATURAL | |
| Insulator Material | POLYAMIDE | |
| JESD-609 Code | e2 | |
| MIL Conformance | NO | |
| Mating Contact Pitch | 0.039 inch | |
| Mating Information | MULTIPAL MATING PARTS AVAILBLE | |
| Mixed Contacts | NO | |
| Mounting Option 1 | LOCKING | |
| Mounting Style | RIGHT ANGLE | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Number Of PCB Rows | 1 | |
| Number of Rows Loaded | 1 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -25 °C | |
| Option | GENERAL PURPOSE | |
| PCB Contact Pattern | RECTANGULAR | |
| Polarization Key | POLARIZED HOUSING | |
| Rated Current (Signal) | 1 A | |
| Reference Standard | UL | |
| Terminal Pitch | 1 mm | |
| Termination Type | SURFACE MOUNT | |
| Total Number of Contacts | 6 | |
| UL Flammability Code | 94V-0 |
Alternate Parts for SM06B-SRSS-TB(LF)(SN)
This table gives cross-reference parts and alternative options found for SM06B-SRSS-TB(LF)(SN). The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of SM06B-SRSS-TB(LF)(SN), but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SM06B-GHS-GB-TB(LF)(SN) | JST Manufacturing | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Right Angle, 0.049 inch Pitch, Surface Mount Terminal, Locking, Natural Insulator, | SM06B-SRSS-TB(LF)(SN) vs SM06B-GHS-GB-TB(LF)(SN) |
| 951106-8622-AR | 3M Interconnect | $0.2609 | Board Connector, 6 Contact(s), 1 Row(s), Male, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, ROHS COMPLIANT | SM06B-SRSS-TB(LF)(SN) vs 951106-8622-AR |
| 155206-6402-RB | 3M Interconnect | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Latch & Eject, Black Insulator, Receptacle, ROHS COMPLIANT | SM06B-SRSS-TB(LF)(SN) vs 155206-6402-RB |
| 104430-4 | TE's AMP | Check for Price | 6 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER | SM06B-SRSS-TB(LF)(SN) vs 104430-4 |
| 155206-6303-RB | 3M Interconnect | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Latch & Eject, Black Insulator, Receptacle, ROHS COMPLIANT | SM06B-SRSS-TB(LF)(SN) vs 155206-6303-RB |
| DF14A-6P-1.25H(52) | Hirose Electric Co Ltd | $1.2250 | Board Connector, 6 Contact(s), 1 Row(s), Male, Right Angle, 0.049 inch Pitch, Surface Mount Terminal, Locking, Beige Insulator, | SM06B-SRSS-TB(LF)(SN) vs DF14A-6P-1.25H(52) |
| 10114831-11106LF | Amphenol FCi | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Right Angle, 0.049 inch Pitch, Solder Terminal, Locking, Natural Insulator, Receptacle, ROHS COMPLIANT | SM06B-SRSS-TB(LF)(SN) vs 10114831-11106LF |
| 53022-0610 | Molex | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Straight, 0.059 inch Pitch, Solder Terminal, Guide Slot, Receptacle | SM06B-SRSS-TB(LF)(SN) vs 53022-0610 |
| 1734261-6 | TE Connectivity | Check for Price | 1.25 WTB, HDR, SMT, RA, 6P | SM06B-SRSS-TB(LF)(SN) vs 1734261-6 |
| 10114831-10106LF | Amphenol FCi | Check for Price | Board Connector, 6 Contact(s), 1 Row(s), Male, Right Angle, 0.049 inch Pitch, Solder Terminal, Locking, Natural Insulator, Receptacle, ROHS COMPLIANT | SM06B-SRSS-TB(LF)(SN) vs 10114831-10106LF |
SM06B-SRSS-TB(LF)(SN) Frequently Asked Questions (FAQ)
-
The recommended torque for the screw terminals is 0.5-1.0 N·m (4.4-8.8 lb·in).
-
Yes, the SM06B-SRSS-TB(LF)(SN) is designed to withstand vibrations and is suitable for use in high-vibration environments.
-
The operating temperature range for the SM06B-SRSS-TB(LF)(SN) is -25°C to 85°C (-13°F to 185°F).
-
Yes, the SM06B-SRSS-TB(LF)(SN) is designed for automated assembly and can be used with pick-and-place machines.
-
The mating cycle life of the SM06B-SRSS-TB(LF)(SN) is 500 cycles minimum.
