SIP32432DR3-T1GE3 Information
SIP32432DR3-T1GE3 by Vishay Intertechnologies is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for SIP32432DR3-T1GE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
23AH3588
|
Newark | Ic, bi Directio Load Switch,1.0A,1.5-5.5V, Msl:Msl 1 - Unlimited, Svhc:No Svhc (15-Jan-2019) Rohs Compliant: Yes |Vishay SIP32432DR3-T1GE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5 |
|
$0.0900 | Buy Now |
|
DISTI #
SIP32432DR3-T1GE3
|
Avnet Americas | Power Switch High Side 1.2A 6-Pin SC-70 T/R - Tape and Reel (Alt: SIP32432DR3-T1GE3) RoHS: Not Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks, 0 Days Container: Reel | 0 |
|
$0.2165 / $0.2300 | Buy Now |
|
DISTI #
78-SIP32432DR3-T1GE3
|
Mouser Electronics | Power Switch ICs - Power Distribution 10pA 1.5V-5.5V LD SW SC-70-6 RoHS: Compliant | 4236 |
|
$0.2450 / $0.5900 | Buy Now |
|
DISTI #
A03:0893_10058494
|
Arrow Electronics | Power Switch Hi Side 1-OUT 1.4A 395mOhm 6-Pin SC-70 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks Date Code: 2449 | Asia - 138000 |
|
$0.1735 / $0.1824 | Buy Now |
|
DISTI #
78417063
|
Verical | Power Switch Hi Side 1-OUT 1.4A 395mOhm 6-Pin SC-70 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 | Americas - 138000 |
|
$0.1735 / $0.1824 | Buy Now |
|
DISTI #
SIP32432DR3-T1GE3
|
TTI | Power Switch ICs - Power Distribution 10pA 1.5V-5.5V LD SW SC-70-6 RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel |
Americas - 6000 In Stock |
|
$0.2180 / $0.2360 | Buy Now |
|
DISTI #
SIP32432DR3-T1GE3
|
TTI | Power Switch ICs - Power Distribution 10pA 1.5V-5.5V LD SW SC-70-6 RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel |
Americas - 6000 In Stock |
|
$0.2180 / $0.2360 | Buy Now |
|
DISTI #
SIP32432DR3-T1GE3
|
EBV Elektronik | Power Switch High Side 12A 6Pin SC70 TR (Alt: SIP32432DR3-T1GE3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for SIP32432DR3-T1GE3
SIP32432DR3-T1GE3 CAD Models
SIP32432DR3-T1GE3 Part Data Attributes
|
|
SIP32432DR3-T1GE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
SIP32432DR3-T1GE3
Vishay Intertechnologies
Buffer/Inverter Based Peripheral Driver,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | SC-70, 6 PIN | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 14 Weeks | |
| Date Of Intro | 2018-11-03 | |
| Samacsys Manufacturer | Vishay | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| JESD-30 Code | R-PDSO-G6 | |
| Length | 2.1 mm | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP6,.08 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Seated Height-Max | 1.1 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 1.5 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Width | 1.25 mm |
