Inductors / Fixed Inductors / SDR1006-470KL
Datasheets
SDR1006-470KL by: Bourns Inc

General Purpose Inductor, 47uH, 10%, 1 Element, Ferrite-Core, SMD, ROHS COMPLIANT

Part Details for SDR1006-470KL by Bourns Inc

Results Overview of SDR1006-470KL by Bourns Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

SDR1006-470KL Information

SDR1006-470KL by Bourns Inc is a Fixed Inductor.
Fixed Inductors are under the broader part category of Inductors.

Inductors are passive components that resist sudden changes in current by storing and releasing energy in an electromagnetic fiel. They are often used in power circuits and energy storage. Read more about Inductors on our Inductors part category page.

Price & Stock for SDR1006-470KL

Part # Distributor Description Stock Price Buy
DISTI # 81AC9864
Newark Ind9.8X9.8X5.8Mm,47Uh10%1.25A, non-Shdsmd Rohs Compliant: Yes |Bourns SDR1006-470KL RoHS: Compliant Min Qty: 800 Package Multiple: 1 Date Code: 0 Container: Reel 800
  • 800 $0.3920
  • 1,600 $0.3910
  • 3,200 $0.3900
$0.3900 / $0.3920 Buy Now
DISTI # 38AC2316
Newark Inductor, 47Uh, 1.25A, 10%, Unshielded, Inductance:47Μh, Rms Current (Irms):1.25A, Inductor Construction:Unshielded, Saturation Current (Isat):2.3A, Product Range:Sdr1006 Series, Power Inductor Case:9.8Mm X 9.8Mm X 5.8Mm, Dc Rohs Compliant: Yes |Bourns SDR1006-470KL RoHS: Compliant Min Qty: 800 Package Multiple: 1 Date Code: 1 Container: Reel 800
  • 800 $0.4470
  • 1,600 $0.4460
  • 3,200 $0.4450
$0.4450 / $0.4470 Buy Now
DISTI # 23T1176
Newark Surface Mount Power Inductor, Sdr1006 Series, 47 H, 10%, Unshielded, 0.17 Ohm, 1.25 A Rohs Compliant: Yes |Bourns SDR1006-470KL RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 200
  • 1 $0.6200
  • 10 $0.5900
  • 25 $0.5740
  • 50 $0.5590
  • 100 $0.5430
  • 250 $0.5290
  • 500 $0.5150
  • 1,000 $0.4480
$0.4480 / $0.6200 Buy Now
DISTI # SDR1006-470KLCT-ND
DigiKey FIXED IND 47UH 1.25A 170MOHM SMD Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 2242
In Stock
  • 1 $0.6600
  • 10 $0.5460
  • 100 $0.4490
  • 800 $0.3763
  • 1,600 $0.3548
  • 2,400 $0.3428
  • 4,000 $0.3283
  • 5,600 $0.3191
  • 8,000 $0.3097
  • 20,000 $0.2975
$0.2975 / $0.6600 Buy Now
DISTI # SDR1006-470KL
Avnet Americas Power Inductor (SMD), 47 uH, ? 10%, 1.25 A, Unshielded, 2.3 A, 9.8mm x 9.8mm x 5.8mm - Tape and Reel (Alt: SDR1006-470KL) RoHS: Compliant Min Qty: 800 Package Multiple: 800 Lead time: 12 Weeks, 0 Days Container: Reel 800
  • 800 $0.2892
  • 1,600 $0.2640
  • 3,200 $0.2607
  • 4,800 $0.2574
  • 6,400 $0.2541
$0.2541 / $0.2892 Buy Now
DISTI # 652-SDR1006-470KL
Mouser Electronics Power Inductors - SMD 47uH 10% SMD 1006 RoHS: Compliant 916
  • 1 $0.4900
  • 10 $0.4600
  • 100 $0.4130
  • 500 $0.3850
  • 800 $0.3180
  • 2,400 $0.3150
$0.3150 / $0.4900 Buy Now
DISTI # E02:0323_00119202
Arrow Electronics Inductor Power Unshielded Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 0.17Ohm DCR T/R RoHS: Compliant Min Qty: 800 Package Multiple: 800 Lead time: 14 Weeks Date Code: 2324 Europe - 800
  • 800 $0.3129
  • 1,600 $0.3098
  • 2,400 $0.3068
  • 4,000 $0.3061
  • 5,600 $0.2992
  • 8,000 $0.2923
  • 20,000 $0.2843
$0.2843 / $0.3129 Buy Now
DISTI # V72:2272_06260584
Arrow Electronics Inductor Power Unshielded Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 0.17Ohm DCR T/R RoHS: Compliant Min Qty: 313 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2216 Container: Cut Strips Americas - 519
  • 308 $0.3248
  • 500 $0.3194
$0.3194 / $0.3248 Buy Now
DISTI # 70153848
RS SDR1006 WireWound SMDinductor w/ FerriteCore,47 uH +/-10%WireWound 2.3A Idc Q:20 Min Qty: 800 Package Multiple: 1 Lead time: 17 Weeks, 0 Days Container: Bulk 0
  • 800 $0.5400
  • 4,000 $0.5000
  • 8,000 $0.4600
  • 80,000 $0.4200
  • 200,000 $0.3800
$0.3800 / $0.5400 RFQ
Onlinecomponents.com Inductor Power Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 170mOhm DCR T/R RoHS: Compliant 8000 In Stock
  • 800 $0.3585
  • 1,600 $0.3342
  • 3,200 $0.3255
  • 5,600 $0.3133
  • 8,000 $0.3086
  • 10,400 $0.3039
  • 15,200 $0.2994
  • 25,600 $0.2949
$0.2949 / $0.3585 Buy Now
DISTI # 62290451
Verical Inductor Power Unshielded Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 0.17Ohm DCR T/R RoHS: Compliant Min Qty: 800 Package Multiple: 800 Date Code: 2215 Americas - 8000
  • 800 $0.4218
  • 1,600 $0.3932
  • 3,200 $0.3829
  • 5,600 $0.3686
  • 8,000 $0.3631
$0.3631 / $0.4218 Buy Now
DISTI # 69713315
Verical Inductor Power Unshielded Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 0.17Ohm DCR T/R RoHS: Compliant Min Qty: 800 Package Multiple: 800 Date Code: 2324 Americas - 800
  • 800 $0.2617
  • 1,600 $0.2590
  • 2,400 $0.2565
  • 4,000 $0.2539
  • 5,600 $0.2513
  • 8,000 $0.2488
  • 20,000 $0.2463
$0.2463 / $0.2617 Buy Now
DISTI # 62306837
Verical Inductor Power Unshielded Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 0.17Ohm DCR T/R RoHS: Compliant Min Qty: 313 Package Multiple: 1 Date Code: 2216 Americas - 519
  • 313 $0.3248
$0.3248 Buy Now
Bristol Electronics   Min Qty: 7 1098
  • 7 $0.7500
  • 28 $0.4875
  • 104 $0.2812
  • 357 $0.2400
  • 772 $0.2100
$0.2100 / $0.7500 Buy Now
Quest Components   1452
  • 1 $1.1000
  • 92 $0.5500
  • 365 $0.4400
$0.4400 / $1.1000 Buy Now
Quest Components   878
  • 1 $1.0000
  • 121 $0.3000
  • 668 $0.2600
$0.2600 / $1.0000 Buy Now
DISTI # SDR1006-470KL
TTI Power Inductors - SMD 47uH 10% SMD 1006 pbFree: Pb-Free Min Qty: 800 Package Multiple: 800 Container: Reel Americas - 0
  • 800 $0.3670
$0.3670 Buy Now
DISTI # SDR1006-470KL
TME Inductor: wire, SMD, 47uH, 1.25A, ±10%, Q: 20, Ø: 10mm, H: 6mm, 170mΩ Min Qty: 1 0
  • 1 $0.5050
  • 50 $0.4280
  • 100 $0.3990
  • 250 $0.3590
  • 400 $0.3540
$0.3540 / $0.5050 RFQ
DISTI # SDR1006-470KL
IBS Electronics INDUCTOR POWER WIREWOUND 47UH 10% 1KHZ 20Q-FACTOR FERRITE 1.25A 170MOHM DCR T/R Min Qty: 800 Package Multiple: 1 8000
  • 800 $0.4661
  • 1,600 $0.4345
  • 3,200 $0.4232
  • 5,600 $0.4073
  • 8,000 $0.4012
  • 10,400 $0.3951
  • 15,200 $0.3892
  • 25,600 $0.3834
$0.3834 / $0.4661 Buy Now
NexGen Digital   2178
RFQ
DISTI # SMC-SDR1006-470KL
Sensible Micro Corporation Inductor Pwr 47Uh 10% RoHS: Compliant Min Qty: 25 Lead time: 0 Weeks, 1 Days Date Code: 1728+ Container: Tape & Reel 1400
  • 100 $0.2047
  • 500 $0.1995
  • 1,000 $0.1890
$0.1890 / $0.2047 RFQ
DISTI # SDR1006-470KL
Avnet Abacus Power Inductor SMD 47 uH 10 125 A Unshielded 23 A 98mm x 98mm x 58mm - Tape and Reel (Alt: SDR1006-470KL) RoHS: Compliant Min Qty: 800 Package Multiple: 800 Lead time: 13 Weeks, 0 Days Container: Reel Abacus - 0
Buy Now
LCSC 1.25A 47uH 10% 2.3A SMD9.8x9.8mm Power Inductors ROHS 100
  • 1 $0.6986
  • 10 $0.6850
  • 30 $0.6759
  • 100 $0.6654
$0.6654 / $0.6986 Buy Now
Master Electronics Inductor Power Wirewound 47uH 10% 1KHz 20Q-Factor Ferrite 1.25A 170mOhm DCR T/R RoHS: Compliant 8000 In Stock
  • 800 $0.3585
  • 1,600 $0.3342
  • 3,200 $0.3255
  • 5,600 $0.3133
  • 8,000 $0.3086
  • 10,400 $0.3039
  • 15,200 $0.2994
  • 25,600 $0.2949
$0.2949 / $0.3585 Buy Now

Part Details for SDR1006-470KL

SDR1006-470KL Part Data Attributes

Parametric Data
SDR1006-470KL Bourns Inc
Buy Now Datasheet
Compare Parts:
SDR1006-470KL Bourns Inc General Purpose Inductor, 47uH, 10%, 1 Element, Ferrite-Core, SMD, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer BOURNS INC
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8504.50.80.00
Factory Lead Time 12 Weeks
Samacsys Manufacturer Bourns
Case/Size Code 3939
Construction Rectangular
Core Material Ferrite
DC Resistance 0.17 Ω
Inductance-Nom (L) 47 µH
Inductor Application POWER INDUCTOR
Inductor Type GENERAL PURPOSE INDUCTOR
JESD-609 Code e2
Number of Functions 1
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Height 5.8 mm
Package Length 9.8 mm
Package Style SMT
Package Width 9.8 mm
Packing Method TR, EMBOSSED PLASTIC/PAPER, 13 Inch
Rated Current-Max 1.25 A
Self Resonance Frequency 8 MHz
Shape/Size Description RECTANGULAR PACKAGE
Shielded NO
Surface Mount YES
Terminal Finish SILVER NICKEL TIN
Terminal Placement DUAL ENDED
Terminal Shape ONE SURFACE
Test Frequency 0.001 MHz
Tolerance 10%

SDR1006-470KL Related Parts

SDR1006-470KL Frequently Asked Questions (FAQ)

  • The recommended land pattern for the SDR1006-470KL can be found in the Bourns Application Note S-8151, which provides guidelines for PCB layout and land pattern design.

  • The SDR1006-470KL has a maximum operating temperature of 125°C. Ensure proper thermal management by providing adequate heat dissipation paths, such as thermal vias, and maintaining a safe distance from heat sources.

  • Bourns recommends a soldering profile with a peak temperature of 240°C to 250°C, with a dwell time of 1-2 seconds. Refer to the Bourns Soldering Application Note S-8153 for more information.

  • Yes, the SDR1006-470KL is designed to withstand vibrations. However, it's essential to ensure proper PCB mounting and secure the component to prevent mechanical stress. Consult the Bourns Reliability and Environmental Testing Application Note S-8152 for more information.

  • The SDR1006-470KL is designed to meet general EMI requirements. However, for specific application requirements, consult the Bourns EMI Filter Application Note S-8154, which provides guidelines for EMI filter design and implementation.
