SCH3221-7U Information
SCH3221-7U by Microchip Technology Inc is a Multifunction Peripheral.
Multifunction Peripherals are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for SCH3221-7U
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
72Y1558
|
Newark | Lpc Io With 8042 Kbc, Reset Generation, Hwm And Multiple Serial Ports 64 Wfbga 6X6X0.8Mm Tray Rohs Compliant: Yes |Microchip SCH3221-7U RoHS: Compliant Min Qty: 490 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$2.4800 | Buy Now |
|
DISTI #
SCH3221-7U-ND
|
DigiKey | IC INTFACE SPECIALIZED 64WFBGA Min Qty: 490 Lead time: 7 Weeks Container: Tray | Temporarily Out of Stock |
|
$2.5625 | Buy Now |
|
DISTI #
SCH3221-7U
|
Avnet Americas | LPC IO WITH 8042 KBC RESET GENERATION HWM AND MULTIPLE SERIAL PORTS - Trays (Alt: SCH3221-7U) RoHS: Compliant Min Qty: 490 Package Multiple: 490 Lead time: 7 Weeks, 0 Days Container: Tray | 0 |
|
$2.4000 / $3.1800 | Buy Now |
|
DISTI #
579-SCH3221-7U
|
Mouser Electronics | I/O Controller Interface IC LPC IO with 8042 KBC Multiple Serial Por RoHS: Compliant | 0 |
|
$2.5600 | Order Now |
|
DISTI #
SCH3221-7U
|
Microchip Technology Inc | LPC IO with Multiple Serial Ports, 8042 KBC, Res Gen, and Hardware Monitoring, WFBGA, Projected EOL: 2044-03-07 COO: China ECCN: EAR99 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Tray |
2700 Alternates Available |
|
$2.1100 / $3.1800 | Buy Now |
|
|
Onlinecomponents.com | LPC I/O with Quad UARTs, GPIO and Wake - 3.3V Supply - 64-WFBGA (6x6) Package - Surface Mount. RoHS: Compliant | 2450 Factory Stock |
|
$2.5400 / $5.3100 | Buy Now |
|
|
Bristol Electronics | 2125 |
|
RFQ | ||
|
|
Quest Components | 1700 |
|
$2.0832 / $5.9520 | Buy Now | |
|
|
Quest Components | 1700 |
|
$3.5712 / $7.1424 | Buy Now | |
|
|
NAC | LPC IO with 8042 KBC, Reset Generation, HWM and Multiple Serial Ports - Package: 64 WFBGA 6x6x0.8mm TRAY RoHS: Compliant Min Qty: 490 Package Multiple: 490 Container: Tray | 0 |
|
$2.5000 / $3.0100 | Buy Now |
Part Details for SCH3221-7U
SCH3221-7U CAD Models
SCH3221-7U Part Data Attributes
|
|
SCH3221-7U
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
SCH3221-7U
Microchip Technology Inc
MULTIFUNCTION PERIPHERAL
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Package Description | WFBGA-64 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 7 Weeks | |
| Date Of Intro | 2016-02-29 | |
| Samacsys Manufacturer | Microchip | |
| Address Bus Width | 4 | |
| Boundary Scan | NO | |
| Bus Compatibility | IRDA; LPC; PCI; UART | |
| External Data Bus Width | 4 | |
| JESD-30 Code | S-PBGA-B64 | |
| JESD-609 Code | e1 | |
| Length | 6 mm | |
| Number of I/O Lines | 33 | |
| Number of Terminals | 64 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VFBGA | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY, VERY THIN PROFILE, FINE PITCH | |
| Screening Level | TS 16949 | |
| Seated Height-Max | 0.8 mm | |
| Supply Voltage-Max | 3.63 V | |
| Supply Voltage-Min | 2.97 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | BALL | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | BOTTOM | |
| Width | 6 mm |
