3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for S7AWF by NKK Switches
Results Overview of S7AWF by NKK Switches
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Internet of Things (IoT)
Environmental Monitoring
Financial Technology (Fintech)
Smart Cities
Transportation and Logistics
Agriculture Technology
Telecommunications
Virtual Reality (VR), Augmented Reality (AR), and Vision Systems
Education and Research
Consumer Electronics
Security and Surveillance
Audio and Video Systems
Computing and Data Storage
Healthcare
Entertainment and Gaming
S7AWF Information
S7AWF by NKK Switches is a Toggle Switch.
Toggle Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for S7AWF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
10X9520
|
Newark | Toggle Sw, Dpdt, 20A/125Vac/30Vdc, Panel, Switch Operation:On-Off-On, Contact Configuration:Dpdt, Illumination:Non Illuminated, Product Range:S Series, Switch Mounting:Panel Mount, Contact Current Max:20A, Contact Voltage Ac Nom:125Vrohs Compliant: Yes |Nkk Switches S7AWF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$22.4700 / $37.6400 | Buy Now |
|
DISTI #
633-S7AWF
|
Mouser Electronics | Toggle Switches SWITCH ROTARY RoHS: Compliant | 0 |
|
$17.1900 / $24.3700 | Order Now |
|
DISTI #
70367314
|
RS | Switch, Toggle, Sealed, DPDT, ON-OFF-ON, Non-Illum,17.50mm Act,20A,125VAC,.250" QC Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks, 0 Days Container: Bulk | 0 |
|
$19.0100 / $24.6800 | RFQ |
|
DISTI #
S7AWF
|
TTI | Toggle Switches SWITCH ROTARY Min Qty: 1 Package Multiple: 1 Container: Bulk |
Americas - 27 In Stock |
|
$18.4300 / $24.3400 | Buy Now |
|
|
Powell Electronics | MEDIUM CAPACITY STANDARD SIZE PANEL SEAL Min Qty: 1 | 37 |
|
$16.6300 / $24.8000 | Buy Now |
Part Details for S7AWF
S7AWF CAD Models
S7AWF Part Data Attributes
|
|
S7AWF
NKK Switches
Buy Now
Datasheet
|
Compare Parts:
S7AWF
NKK Switches
Toggle Switch, DPDT, On-off-on, 20A, 30VDC, Quick Connect Terminal, Toggle Actuator, Panel Mount
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NKK SWITCHES CO LTD | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.50.70.00 | |
| Samacsys Manufacturer | NKK Switches | |
| Actuator Angle | 28 deg | |
| Actuator Finish | CHROME | |
| Actuator Length | 0.689 inch | |
| Actuator Material | BRASS | |
| Actuator Type | TOGGLE | |
| Body Breadth | 18.5928 mm | |
| Body Height | 20.0152 mm | |
| Body Length or Diameter | 31.1912 mm | |
| Bushing Diameter | 0.472 inch | |
| Bushing Length | 0.295 inch | |
| Bushing Type | M12P1 | |
| Center Contact Plating | SILVER | |
| Contact (AC) Max Rating R Load | 10A@250VAC | |
| Contact Current(AC)-Max | 10 A | |
| Contact Current(DC)-Max | 20 A | |
| Contact (DC) Max Rating R Load | 20A@30VDC | |
| Contact Function | ON-OFF-ON | |
| Contact Resistance | 0.01 mΩ | |
| Contact Voltage(AC)-Max | 250 V | |
| Contact Voltage(DC)-Max | 30 V | |
| Dielectric Withstand Volts | 2000VAC V | |
| Electrical Life | 25000 Cycle(s) | |
| End Contact Plating | SILVER | |
| Insulation Resistance | 1000000000 Ω | |
| Insulator Material | PHENOLIC | |
| JESD-609 Code | e3 | |
| Mounting Feature | PANEL MOUNT | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -10 °C | |
| Solderability | HAND | |
| Surface Mount | NO | |
| Switch Function | DPDT | |
| Switch Type | TOGGLE SWITCH | |
| Terminal Finish | Tin (Sn) | |
| Terminal Length | 0.461 inch | |
| Terminal Material | BRASS | |
| Termination Type | QUICK CONNECT |
S7AWF Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for the S7AWF switch is -20°C to 85°C, although it can withstand storage temperatures from -40°C to 100°C.
-
The S7AWF switch is rated for a minimum of 10,000 cycles, but it can withstand up to 50,000 cycles or more depending on the operating conditions and usage.
-
Yes, the S7AWF switch is designed to withstand high-vibration environments and can operate reliably in applications with vibrations up to 10G.
-
The S7AWF switch has a rating of IP67, which means it is protected against dust and can withstand immersion in water up to 1 meter for 30 minutes. However, it's recommended to use a sealant or conformal coating to ensure reliability in humid or wet environments.
-
The recommended torque for the S7AWF switch's actuator is 0.5 N·m to 1.5 N·m. Over-tightening can damage the switch, so it's essential to follow the recommended torque specification.
