S1210R-562K Information
S1210R-562K by API Delevan is a Fixed Inductor.
Fixed Inductors are under the broader part category of Inductors.
Inductors are passive components that resist sudden changes in current by storing and releasing energy in an electromagnetic fiel. They are often used in power circuits and energy storage. Read more about Inductors on our Inductors part category page.
Price & Stock for S1210R-562K
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
DN7928CT-ND
|
DigiKey | FIXED IND 5.6UH 352MA 1.3OHM SMD Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
856 In Stock |
|
$1.6500 / $3.1000 | Buy Now |
|
DISTI #
807-S1210R-562K
|
Mouser Electronics | RF Inductors - SMD 5.6uH 10% RoHS: Compliant | 157 |
|
$1.6500 / $3.1000 | Buy Now |
|
|
Quest Components | 1 ELEMENT, 5.6 UH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD | 299 |
|
$1.6020 / $4.0050 | Buy Now |
Part Details for S1210R-562K
S1210R-562K CAD Models
S1210R-562K Part Data Attributes
|
|
S1210R-562K
API Delevan
Buy Now
Datasheet
|
Compare Parts:
S1210R-562K
API Delevan
General Purpose Inductor, 5.6uH, 10%, 1 Element, Ferrite-Core, SMD, 1210, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | API DELEVAN | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8504.50.80.00 | |
| Samacsys Manufacturer | API Delevan | |
| Case/Size Code | 1210 | |
| Construction | Rectangular | |
| Core Material | FERRITE | |
| DC Resistance | 1.3 Ω | |
| Inductance-Nom (L) | 5.6 µH | |
| Inductor Application | RF INDUCTOR | |
| Inductor Type | GENERAL PURPOSE INDUCTOR | |
| JESD-609 Code | e1 | |
| Number of Functions | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 2.57 mm | |
| Package Length | 3.51 mm | |
| Package Style | SMT | |
| Package Width | 2.66 mm | |
| Packing Method | TR, 13 Inch | |
| Quality Factor-Min (at L-nom) | 40 | |
| Rated Current-Max | 0.352 A | |
| Self Resonance Frequency | 38 MHz | |
| Shape/Size Description | RECTANGULAR PACKAGE | |
| Shielded | YES | |
| Surface Mount | YES | |
| Terminal Finish | Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5) | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | J BEND | |
| Test Frequency | 7.9 MHz | |
| Tolerance | 10% |
S1210R-562K Frequently Asked Questions (FAQ)
-
The recommended land pattern for the S1210R-562K is a rectangular pad with a size of 2.5mm x 1.5mm, with a non-solder mask defined (NSMD) pad shape.
-
The S1210R-562K has a maximum operating temperature of 125°C. Ensure good airflow around the inductor, and consider using a heat sink or thermal interface material if operating in high-temperature environments.
-
The SRF of the S1210R-562K is approximately 150 MHz, but this value can vary depending on the specific application and PCB layout.
-
While the S1210R-562K is a high-quality inductor, it may not meet the specific requirements of high-reliability or aerospace applications. Consult with API Delevan or a qualified engineer to determine suitability for such applications.
-
Keep the S1210R-562K at least 5mm away from sensitive components, and consider using shielding or a mu-metal shield to minimize magnetic field interference.
