RF37S114HTFJB Information
RF37S114HTFJB by Texas Instruments is an Other Telecom IC.
Other Telecom ICs are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for RF37S114HTFJB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-RF37S114HTFJB-ND
|
DigiKey | RFID TAG R/W 13.56MHZ INLAY Min Qty: 1 Lead time: 18 Weeks Container: Bulk |
3630 In Stock |
|
$0.4080 / $0.7200 | Buy Now |
|
DISTI #
595-RF37S114HTFJB
|
Mouser Electronics | NFC/RFID Tags & Transponders Tag-it 256b 4mm*4mm RoHS: Compliant | 34918 |
|
$0.4170 / $0.7200 | Buy Now |
|
DISTI #
RF37S114HTFJB
|
Chip One Stop | Semiconductors RoHS: Compliant pbFree: Yes Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Bulk | 4654 |
|
$0.4120 / $0.7440 | Buy Now |
|
|
Vyrian | Telecommunications | 76781 |
|
RFQ |
Part Details for RF37S114HTFJB
RF37S114HTFJB CAD Models
RF37S114HTFJB Part Data Attributes
|
|
RF37S114HTFJB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
RF37S114HTFJB
Texas Instruments
Tag-it HF-I Type 5 NFC, ISO15693 Transponder, 4 mm x 4 mm 0-RFIDN -25 to 70
|
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | MODULE | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | SEATED HT-CALCULATED | |
| JESD-30 Code | S-XXMA-X | |
| Length | 4 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -25 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | XMA | |
| Package Shape | SQUARE | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.76 mm | |
| Surface Mount | YES | |
| Telecom IC Type | TELECOM CIRCUIT | |
| Temperature Grade | OTHER | |
| Terminal Form | UNSPECIFIED | |
| Terminal Position | UNSPECIFIED | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4 mm |
