3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for RB060M-30TR by ROHM Semiconductor
Results Overview of RB060M-30TR by ROHM Semiconductor
- Distributor Offerings: (4 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (2 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
RB060M-30TR Information
RB060M-30TR by ROHM Semiconductor is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for RB060M-30TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
RB060M-30CT-ND
|
DigiKey | DIODE SCHOTTKY 30V 2A PMDU Min Qty: 1 Lead time: 17 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.1010 / $0.6100 | Buy Now |
|
DISTI #
755-RB060M-30TR
|
Mouser Electronics | Schottky Diodes & Rectifiers SCHOTTKYPMDUT/R RoHS: Compliant | 85 |
|
$0.1030 / $0.4700 | Buy Now |
|
DISTI #
62206417
|
Verical | Rectifier Diode Schottky 30V 2A 2-Pin PMDU T/R Min Qty: 252 Package Multiple: 1 Date Code: 2211 | Americas - 1990 |
|
$0.3240 / $0.4320 | Buy Now |
|
DISTI #
59821964
|
Verical | Rectifier Diode Schottky 30V 2A 2-Pin PMDU T/R Min Qty: 343 Package Multiple: 1 Date Code: 2101 | Americas - 842 |
|
$0.2206 / $0.2289 | Buy Now |
Part Details for RB060M-30TR
RB060M-30TR CAD Models
RB060M-30TR Part Data Attributes
|
|
RB060M-30TR
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
RB060M-30TR
ROHM Semiconductor
Rectifier Diode, Schottky, 1 Element, 2A, 30V V(RRM),
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | ROHM CO LTD | |
| Package Description | SOD-123, 2 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 0.45 V | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e1 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 55 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 2 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Rep Pk Reverse Voltage-Max | 30 V | |
| Surface Mount | YES | |
| Technology | SCHOTTKY | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 |
Alternate Parts for RB060M-30TR
This table gives cross-reference parts and alternative options found for RB060M-30TR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RB060M-30TR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SK23 | Diotec Semiconductor AG | $0.0489 | Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 30V V(RRM), Silicon, DO-214AA, ROHS COMPLIANT, PLASTIC, SMB, 2 PIN | RB060M-30TR vs SK23 |
| RB060MM-30TR | ROHM Semiconductor | $0.2326 | Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 30V V(RRM), Silicon, PMDU, 2 PIN | RB060M-30TR vs RB060MM-30TR |
RB060M-30TR Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for the RB060M-30TR is -40°C to 125°C.
-
To ensure reliability, it's recommended to derate the power dissipation of the RB060M-30TR according to the ambient temperature, and to use a heat sink or thermal management system to keep the junction temperature below 150°C.
-
The maximum allowable power dissipation for the RB060M-30TR is 1.5W, but this can be affected by the ambient temperature and the thermal resistance of the package.
-
To prevent damage, handle the RB060M-30TR by the body, avoid touching the leads or die, and store them in an anti-static package or bag to prevent electrostatic discharge (ESD) damage.
-
The recommended soldering temperature is 260°C (peak temperature) and the recommended soldering time is 10 seconds or less to prevent thermal damage to the device.
