R5F564MGCDFP#11 Information
R5F564MGCDFP#11 by Renesas Electronics Corporation is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for R5F564MGCDFP#11
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
559-R5F564MGCDFP#11-ND
|
DigiKey | IC MCU 32BIT 2.5MB FLSH 100LFQFP Min Qty: 1 Lead time: 12 Weeks Container: Tray |
720 In Stock |
|
$11.5317 / $18.0700 | Buy Now |
|
DISTI #
R5F564MGCDFP#11
|
Avnet Americas | Microcontroller 32-Bit RX RXv2 CISC 2.5MB Flash 100-Pin LFQFP - Trays (Alt: R5F564MGCDFP#11) RoHS: Compliant Min Qty: 720 Package Multiple: 720 Lead time: 12 Weeks, 0 Days Container: Tray | 0 |
|
$11.2700 | Buy Now |
|
DISTI #
968-R5F564MGCDFP#11
|
Mouser Electronics | 32-bit Microcontrollers - MCU 32BIT MCU RX64M 2560K/512K QFP100 RoHS: Compliant | 0 |
|
$11.5300 | Order Now |
|
DISTI #
75724185
|
Verical | R5F564MGCDFP#11 Min Qty: 4 Package Multiple: 1 Date Code: 2345 | Americas - 720 |
|
$9.8000 / $17.3000 | Buy Now |
|
DISTI #
R5F564MGCDFP#11
|
Avnet Silica | Microcontroller 32Bit RX RXv2 CISC 25MB Flash 100Pin LFQFP (Alt: R5F564MGCDFP#11) RoHS: Compliant Min Qty: 720 Package Multiple: 720 Lead time: 14 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
R5F564MGCDFP#11
|
Chip One Stop | Semiconductors RoHS: Compliant Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Tray | 720 |
|
$8.7000 / $17.3000 | Buy Now |
Part Details for R5F564MGCDFP#11
R5F564MGCDFP#11 CAD Models
R5F564MGCDFP#11 Part Data Attributes
|
|
R5F564MGCDFP#11
Renesas Electronics Corporation
Buy Now
Datasheet
|
Compare Parts:
R5F564MGCDFP#11
Renesas Electronics Corporation
High Performance 32-bit Microcontrollers Achieving 5.06CoreMark/MHz (607CoreMark) with RXv2 Core Employed, LQFP, /Tray (Full Carton)
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RENESAS ELECTRONICS CORP | |
| Part Package Code | LQFP | |
| Package Description | LFQFP-100 | |
| Pin Count | 144 | |
| Manufacturer Package Code | PLQP0100KB | |
| Reach Compliance Code | unknown | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Renesas Electronics | |
| Has ADC | YES | |
| Additional Feature | 2 EXTERNAL DMA CHANNEL AVAILABLE | |
| Address Bus Width | 24 | |
| Bit Size | 32 | |
| Boundary Scan | YES | |
| CPU Family | RX64M | |
| Clock Frequency-Max | 24 MHz | |
| DAC Channels | YES | |
| DMA Channels | YES | |
| External Data Bus Width | 32 | |
| Format | FLOATING POINT | |
| Integrated Cache | NO | |
| JESD-30 Code | S-PQFP-G100 | |
| Length | 14 mm | |
| Low Power Mode | YES | |
| Moisture Sensitivity Level | 3 | |
| Number of DMA Channels | 8 | |
| Number of External Interrupts | 16 | |
| Number of I/O Lines | 79 | |
| Number of Serial I/Os | 13 | |
| Number of Terminals | 100 | |
| Number of Timers | 23 | |
| On Chip Data RAM Width | 8 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | QFP | |
| Package Equivalence Code | QFP100,.63SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK | |
| RAM (bytes) | 524288 | |
| ROM (words) | 2621440 | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1.7 mm | |
| Speed | 120 MHz | |
| Supply Current-Max | 110 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 3 V | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 14 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
Alternate Parts for R5F564MGCDFP#11
This table gives cross-reference parts and alternative options found for R5F564MGCDFP#11. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of R5F564MGCDFP#11, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
