3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for PSA5A2-2 by Bel Power Solutions
Results Overview of PSA5A2-2 by Bel Power Solutions
- Distributor Offerings: (1 listing)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
PSA5A2-2 Information
PSA5A2-2 by Bel Power Solutions is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for PSA5A2-2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
PSA5A2-2-ND
|
DigiKey | DC DC CONVERTER 5.1V Lead time: 16 Weeks Container: Bulk | Temporarily Out of Stock |
|
Buy Now |
Part Details for PSA5A2-2
PSA5A2-2 CAD Models
PSA5A2-2 Part Data Attributes
|
|
PSA5A2-2
Bel Power Solutions
Buy Now
Datasheet
|
Compare Parts:
PSA5A2-2
Bel Power Solutions
DC/DC CONVERTER 5.1V
|
| Pbfree Code | Yes | |
| Rohs Code | No | |
| Part Life Cycle Code | Transferred | |
| Ihs Manufacturer | POWER-ONE INC | |
| Package Description | METAL, CASE A01, MODULE-6 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Bel Power Solutions | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Approvals | UL, CSA, EN, CE | |
| Efficiency (Main Output) | 75% | |
| Input Voltage-Max | 40 V | |
| Input Voltage-Min | 8 V | |
| Input Voltage-Nom | 20 V | |
| JESD-30 Code | R-MDMA-D6 | |
| JESD-609 Code | e0 | |
| Length | 70.2 mm | |
| Line Regulation-Max | 0.3% | |
| Load Regulation-Max | 0.3% | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 50 °C | |
| Operating Temperature-Min | -10 °C | |
| Output Current-Max | 2 A | |
| Output Voltage-Max | 5.1306 V | |
| Output Voltage-Min | 5.0694 V | |
| Output Voltage-Nom | 5.1 V | |
| Package Body Material | METAL | |
| Package Code | DMA | |
| Package Shape | RECTANGULAR | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Qualification Status | Not Qualified | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | TIN LEAD | |
| Terminal Form | SOLDER LUG | |
| Terminal Position | DUAL | |
| Total Power Output-Max | 10.2 W | |
| Trim/Adjustable Output | NO | |
| Width | 50.2 mm |
