NTNUS3171PZT5G Information
NTNUS3171PZT5G by onsemi is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for NTNUS3171PZT5G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2724421
|
Farnell | MOSFET, P-CH, -20V, -0.15A, SOT-1123 RoHS: Compliant Min Qty: 5 Lead time: 25 Weeks, 1 Days Container: Cut Tape | 1900 |
|
$0.1136 / $0.3736 | Buy Now |
|
DISTI #
2724421RL
|
Farnell | MOSFET, P-CH, -20V, -0.15A, SOT-1123 RoHS: Compliant Min Qty: 100 Lead time: 25 Weeks, 1 Days Container: Reel | 1900 |
|
$0.1136 / $0.1674 | Buy Now |
|
DISTI #
4280992
|
Farnell | RoHS: Compliant Min Qty: 1000 Container: Each | 0 |
|
$0.0991 | Buy Now |
|
DISTI #
4319772
|
Farnell | MOSFET, P-CH, 20V, 0.15A, SOT-1123 RoHS: Compliant Min Qty: 8000 Lead time: 53 Weeks, 2 Days Container: Reel | 0 |
|
$0.0904 / $0.0923 | Buy Now |
|
DISTI #
NTNUS3171PZT5GOSCT-ND
|
DigiKey | MOSFET P-CH 20V 150MA SOT1123 Min Qty: 1 Lead time: 24 Weeks Container: Cut Tape (CT), Tape & Reel (TR) |
133 In Stock |
|
$0.1953 / $0.5000 | Buy Now |
|
DISTI #
NTNUS3171PZT5G
|
Avnet Americas | Trans MOSFET P-CH 20V 0.15A 3-Pin SOT-1123 T/R - Tape and Reel (Alt: NTNUS3171PZT5G) RoHS: Not Compliant Min Qty: 9434 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Reel | 43620 Partner Stock |
|
$0.0720 / $0.0735 | Buy Now |
|
DISTI #
V72:2272_07318371
|
Arrow Electronics | Trans MOSFET P-CH 20V 0.15A 3-Pin SOT-1123 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 24 Weeks Date Code: 2102 Container: Cut Strips | Americas - 73 |
|
$0.0780 / $0.0975 | Buy Now |
|
|
Onlinecomponents.com | Single P-Channel Small Signal MOSFET -20V, -200mA, 3.5Ω RoHS: Compliant |
8000 In Stock |
|
$0.6800 / $0.8400 | Buy Now |
|
DISTI #
86006135
|
Verical | Trans MOSFET P-CH 20V 0.15A 3-Pin SOT-1123 T/R RoHS: Compliant Min Qty: 3513 Package Multiple: 1 Date Code: 1801 | Americas - 596869 |
|
$0.0798 / $0.1068 | Buy Now |
|
DISTI #
86016760
|
Verical | Trans MOSFET P-CH 20V 0.15A 3-Pin SOT-1123 T/R RoHS: Compliant Min Qty: 3513 Package Multiple: 1 Date Code: 1501 | Americas - 336000 |
|
$0.0798 / $0.1068 | Buy Now |
Part Details for NTNUS3171PZT5G
NTNUS3171PZT5G CAD Models
NTNUS3171PZT5G Part Data Attributes
|
|
NTNUS3171PZT5G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NTNUS3171PZT5G
onsemi
Single P-Channel Small Signal MOSFET -20V, -200mA, 3.5Ω, SOT-1123, 1.0x0.6x0.37, 0.35P, 8000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOT-1123, 1.0x0.6x0.37, 0.35P | |
| Pin Count | 3 | |
| Manufacturer Package Code | 524AA | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 2 Days | |
| Samacsys Manufacturer | onsemi | |
| Configuration | SINGLE WITH BUILT-IN DIODE AND RESISTOR | |
| DS Breakdown Voltage-Min | 20 V | |
| Drain Current-Max (ID) | 0.15 A | |
| Drain-source On Resistance-Max | 3.5 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PDSO-F3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | P-CHANNEL | |
| Power Dissipation-Max (Abs) | 0.2 W | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
