NTK3043NT1G Information
NTK3043NT1G by onsemi is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for NTK3043NT1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
81Y7049
|
Newark | Mosfet, N-Ch, 20V, 0.255A, Sot-723, Transistor Polarity:N Channel, Continuous Drain Current Id:255Ma, Drain Source Voltage Vds:20V, On Resistance Rds(On):1.6Ohm, Rds(On) Test Voltage Vgs:4.5V, Threshold Voltage Vgs:1.3V, Power Rohs Compliant: Yes |Onsemi NTK3043NT1G RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 17398 |
|
$0.0930 / $0.2230 | Buy Now |
|
DISTI #
86AK5833
|
Newark | Nfet Sot723 20V 285Ma 3.4, Transistor Polarity:N Channel, Continuous Drain Current Id:285Ma, Drain Source Voltage Vds:20V, On Resistance Rds(On):3.4Ohm, Rds(On) Test Voltage Vgs:4.5V, Threshold Voltage Vgs:400Mv, Power Dissipation Rohs Compliant: Yes |Onsemi NTK3043NT1G RoHS: Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 1 Container: Reel | 8000 |
|
$0.0640 / $0.0670 | Buy Now |
|
DISTI #
NTK3043NT1G
|
Avnet Americas | Trans MOSFET N-CH 20V 0.225A 3-Pin SOT-723 T/R - Tape and Reel (Alt: NTK3043NT1G) RoHS: Compliant Min Qty: 28000 Package Multiple: 4000 Lead time: 10 Weeks, 0 Days Container: Reel | 0 |
|
$0.0369 / $0.0383 | Buy Now |
|
DISTI #
863-NTK3043NT1G
|
Mouser Electronics | MOSFETs NFET 20V 285mA TR RoHS: Compliant | 192651 |
|
$0.0390 / $0.2000 | Buy Now |
|
DISTI #
E02:0323_00078423
|
Arrow Electronics | Trans MOSFET N-CH 20V 0.255A 3-Pin SOT-723 T/R RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 10 Weeks Date Code: 2514 | Europe - 228000 |
|
$0.0402 | Buy Now |
|
DISTI #
V72:2272_07310831
|
Arrow Electronics | Trans MOSFET N-CH 20V 0.255A 3-Pin SOT-723 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2217 Container: Cut Strips | Americas - 1657 |
|
$0.0355 / $0.1480 | Buy Now |
|
DISTI #
V72:2272_26884969
|
Arrow Electronics | Trans MOSFET N-CH 20V 0.255A 3-Pin SOT-723 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2219 Container: Cut Strips | Americas - 175 |
|
$0.0149 / $0.0410 | Buy Now |
|
|
Onlinecomponents.com | Single N-Channel Small Signal MOSFET with ESD Protection 20V, 285mA, 3.4Ω RoHS: Compliant |
24000 In Stock |
|
$0.0376 / $0.0430 | Buy Now |
|
DISTI #
88786671
|
Verical | Trans MOSFET N-CH 20V 0.255A 3-Pin SOT-723 T/R RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Date Code: 2514 | Americas - 228000 |
|
$0.0399 | Buy Now |
|
DISTI #
83637493
|
Verical | Trans MOSFET N-CH 20V 0.255A 3-Pin SOT-723 T/R RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Date Code: 2426 | Americas - 24000 |
|
$0.0516 / $0.0559 | Buy Now |
Part Details for NTK3043NT1G
NTK3043NT1G CAD Models
NTK3043NT1G Part Data Attributes
|
|
NTK3043NT1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NTK3043NT1G
onsemi
Single N-Channel Small Signal MOSFET with ESD Protection 20V, 285mA, 3.4Ω, SOT-723 3 LEAD, 4000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOT-723 3 LEAD | |
| Package Description | CASE 631AA-01, 3 PIN | |
| Pin Count | 3 | |
| Manufacturer Package Code | 631AA | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 10 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | LOGIC LEVEL COMPATIBLE | |
| Configuration | SINGLE WITH BUILT-IN DIODE AND RESISTOR | |
| DS Breakdown Voltage-Min | 20 V | |
| Drain Current-Max (ID) | 0.21 A | |
| Drain-source On Resistance-Max | 3.8 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PDSO-F3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 0.545 W | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
