NHD-C0216CZ-FSW-FBW-3V3 Information
NHD-C0216CZ-FSW-FBW-3V3 by Newhaven Display International is a Display.
Displays are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| DAO3V3SA00LF | Amphenol Communications Solutions | DAO3V3SA00LF-DSUB POWER STB 3V3 S | |
| DAL3V3SA00LF | Amphenol Communications Solutions | DSUB POWER-STB 3V3 SOCK | |
| DA3V3P300A30LF | Amphenol Communications Solutions | DA3V3P300A30LF-DSUB POWER STB 3V3 PIN |
Price & Stock for NHD-C0216CZ-FSW-FBW-3V3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
NHD-C0216CZ-FSW-FBW-3V3-ND
|
DigiKey | LCD MOD 32DIG 16X2 TRANSFLCT WHT Min Qty: 1 Lead time: 18 Weeks Container: Bulk |
668 In Stock |
|
$9.1801 / $12.7500 | Buy Now |
|
DISTI #
763-C0216CZ-FSWFBW3V
|
Mouser Electronics | LCD Character Display Modules & Accessories FSTN (+) Transfl 41.4 x 24.3 x 4.0 RoHS: Compliant | 1099 |
|
$11.0700 / $12.7500 | Buy Now |
|
DISTI #
70518230
|
RS | Character Display Modules LCD COG NHD Series 16x2 FSTN + Transflect 4-Bit SPI Min Qty: 1 Package Multiple: 1 Container: Bulk | 0 |
|
$19.4600 / $22.8900 | RFQ |
|
|
Onlinecomponents.com | Chip on Glass - 2 x 16 Character - FSTN (+) - White 3V Backlight - 41.4 x 24.3 x 4.0 mm RoHS: Compliant |
2201 In Stock |
|
$8.9100 / $11.5400 | Buy Now |
|
DISTI #
NHD-C0216CZ-FWF3
|
TME | Display: LCD, alphanumeric, COG,FSTN Positive, 16x2, white, LED Min Qty: 1 | 76 |
|
$10.9000 / $12.4000 | Buy Now |
|
|
Master Electronics | Chip on Glass - 2 x 16 Character - FSTN (+) - White 3V Backlight - 41.4 x 24.3 x 4.0 mm RoHS: Compliant |
2201 In Stock |
|
$8.9100 / $11.5400 | Buy Now |
Part Details for NHD-C0216CZ-FSW-FBW-3V3
NHD-C0216CZ-FSW-FBW-3V3 CAD Models
NHD-C0216CZ-FSW-FBW-3V3 Part Data Attributes
|
|
NHD-C0216CZ-FSW-FBW-3V3
Newhaven Display International
Buy Now
Datasheet
|
Compare Parts:
NHD-C0216CZ-FSW-FBW-3V3
Newhaven Display International
Display
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NEWHAVEN DISPLAY INTERNATIONAL INC | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Newhaven Display | |
| Backlight | LED-WHITE | |
| Display Format | 16 X 2 | |
| Display Height | 4.13 mm | |
| Fluid Type | FSTN POSITIVE | |
| Number of Functions | 1 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -20 °C | |
| Optoelectronic Device Type | 5 X 8 DOT MATRIX LCD DISPLAY | |
| Polarization Mode | TRANSFLECTIVE | |
| Supply Voltage-Nom | 5.5 V | |
| Viewing Area Height | 13 mm | |
| Viewing Area Length | 38 mm |
NHD-C0216CZ-FSW-FBW-3V3 Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for the NHD-C0216CZ-FSW-FBW-3V3 is -20°C to 70°C.
-
The display module requires a power-on reset (POR) sequence to initialize. Apply VCC (3.3V) to the module, then apply a logic high to the RESET pin, and finally, apply a clock signal to the SCL pin.
-
The maximum current consumption of the NHD-C0216CZ-FSW-FBW-3V3 is approximately 25mA, depending on the display mode and backlight usage.
-
The NHD-C0216CZ-FSW-FBW-3V3 is not designed for use in humid environments. It is recommended to use the display module in a dry, clean environment to prevent damage or malfunction.
-
The backlight brightness can be adjusted by applying a PWM signal to the BLK pin. The duty cycle of the PWM signal controls the brightness of the backlight.
