Part Details for NCV2901DTBR2G by onsemi
Results Overview of NCV2901DTBR2G by onsemi
- Distributor Offerings: (25 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
NCV2901DTBR2G Information
NCV2901DTBR2G by onsemi is a Comparator.
Comparators are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for NCV2901DTBR2G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
34M7793
|
Newark | Analogue Comparator, Quad, Low Offset Voltage, 4, 1.3 S, 3V To 30V, Tssop, 14 |Onsemi NCV2901DTBR2G RoHS: Not Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1950 / $0.2530 | Buy Now |
|
DISTI #
38AH1411
|
Newark | Ana Sngl Sup Compt Qud Rohs Compliant: Yes |Onsemi NCV2901DTBR2G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1430 | Buy Now |
|
DISTI #
488-NCV2901DTBR2GCT-ND
|
DigiKey | IC COMPARATOR 4 GEN PUR 14TSSOP Min Qty: 1 Lead time: 7 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
3698 In Stock |
|
$0.2039 / $0.5000 | Buy Now |
|
DISTI #
NCV2901DTBR2G
|
Avnet Americas | Analogue Comparator, Quad, Low Offset Voltage, 4 Channels, 1.3 ?s, 3V to 30V, TSSOP, 14 Pins - Tape and Reel (Alt: NCV2901DTBR2G) RoHS: Compliant Min Qty: 3572 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Reel | 225000 Partner Stock |
|
$0.1728 / $0.1892 | Buy Now |
|
DISTI #
NCV2901DTBR2G
|
Avnet Americas | Analogue Comparator, Quad, Low Offset Voltage, 4 Channels, 1.3 ?s, 3V to 30V, TSSOP, 14 Pins - Tape and Reel (Alt: NCV2901DTBR2G) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 7 Weeks, 0 Days Container: Reel | 0 |
|
$0.1334 / $0.1428 | Buy Now |
|
DISTI #
863-NCV2901DTBR2G
|
Mouser Electronics | Analog Comparators ANA SGL SUP CMP QUAD RoHS: Compliant | 4390 |
|
$0.1900 / $1.0400 | Buy Now |
|
DISTI #
V36:1790_07285091
|
Arrow Electronics | Comparator Quad ±18V/36V Automotive AEC-Q100 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 7 Weeks Date Code: 2425 | Americas - 2500 |
|
$0.1873 / $0.1954 | Buy Now |
|
DISTI #
70467179
|
RS | NCV2901DTBR2G Quad Comparator, Swing O/P, 300ns 36 V 14-Pin TSSOP Min Qty: 1 Package Multiple: 1 Container: Bulk | 0 |
|
$0.4530 / $0.5330 | RFQ |
|
|
Onlinecomponents.com | Comparator, Quad, Single Supply, 36V RoHS: Compliant | 0 |
|
$0.1789 / $0.2034 | Buy Now |
|
DISTI #
86000823
|
Verical | Comparator Quad ±18V/36V Automotive AEC-Q100 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 1419 Package Multiple: 1 Date Code: 2301 | Americas - 45000 |
|
$0.1975 / $0.2644 | Buy Now |
Part Details for NCV2901DTBR2G
NCV2901DTBR2G CAD Models
NCV2901DTBR2G Part Data Attributes
|
|
NCV2901DTBR2G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NCV2901DTBR2G
onsemi
Comparator, Quad, Single Supply, 36V, TSSOP-14, 2500-REEL, Automotive Qualified
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | TSSOP-14 | |
| Pin Count | 14 | |
| Manufacturer Package Code | 948G | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 2 Days | |
| Samacsys Manufacturer | onsemi | |
| Amplifier Type | COMPARATOR | |
| Average Bias Current-Max (IIB) | 0.5 µA | |
| Bias Current-Max (IIB) @25C | 0.25 µA | |
| Input Offset Voltage-Max | 15000 µV | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e4 | |
| Length | 5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 4 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Type | OPEN-COLLECTOR | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP14,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Response Time-Nom | 1300 ns | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.2 mm | |
| Supply Current-Max | 2.5 mA | |
| Supply Voltage Limit-Max | 36 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 mm |
