NCD98010XMXTAG Information
NCD98010XMXTAG by onsemi is an Analog to Digital Converter.
Analog to Digital Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for NCD98010XMXTAG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
74AH4790
|
Newark | Adc, Sar, 12Bit, 2Msps, X2Qfn-8 Rohs Compliant: Yes |Onsemi NCD98010XMXTAG RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 9357 |
|
$0.7550 / $1.1800 | Buy Now |
|
DISTI #
488-NCD98010XMXTAGCT-ND
|
DigiKey | IC ADC 12BIT 8X2QFN Min Qty: 1 Lead time: 32 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
7127 In Stock |
|
$0.7600 / $1.5900 | Buy Now |
|
DISTI #
NCD98010XMXTAG
|
Avnet Americas | Analog to Digital Converter, 12 bit, SAR, 2 MSPS, Differential, SPI, 1.65 V to 3.6 V, 8 Pins, X2QFN - Tape and Reel (Alt: NCD98010XMXTAG) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 32 Weeks, 0 Days Container: Reel | 5000 Factory Stock |
|
$0.7006 / $0.7669 | Buy Now |
|
DISTI #
863-NCD98010XMXTAG
|
Mouser Electronics | Analog to Digital Converters - ADC 12-BIT 2 MSPS SAR ADC - SINGLE CHANNEL X2QFN PACKAGE-SINGLE ENDED OUTPUT RoHS: Compliant | 8518 |
|
$0.6810 / $2.5700 | Buy Now |
|
DISTI #
V72:2272_24404787
|
Arrow Electronics | 1-Channel Single ADC SAR 2Msps 12-bit Serial 8-Pin X2QFN T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 32 Weeks Date Code: 2240 Container: Cut Strips | Americas - 4875 |
|
$0.7278 / $0.8144 | Buy Now |
|
|
Onlinecomponents.com | 12-Bit 2 Msps Sar Adc - Single Channel X2Qfn Package-Single Ended Output / Reel RoHS: Compliant | 0 |
|
$0.7040 / $1.9290 | Buy Now |
|
DISTI #
88108056
|
Verical | 1-Channel Single ADC SAR 2Msps 12-bit Serial 8-Pin X2QFN T/R RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 | Americas - 5000 |
|
$0.7138 | Buy Now |
|
|
Rochester Electronics | NCD98010 - 12-Bit Low Power SAR ADC Unsigned Output X2QFN RoHS: Compliant Status: Active Min Qty: 1 | 18046 |
|
$0.5959 / $0.9611 | Buy Now |
|
DISTI #
NCD98010XMXTAG
|
IBS Electronics | 12-BIT 2 MSPS SAR ADC - SINGLE CHANNEL X2QFN PACKAGE-SINGLE ENDED OUTPUT / REEL Min Qty: 5000 Package Multiple: 1 | 0 |
|
$0.8710 | Buy Now |
|
DISTI #
NCD98010XMXTAG
|
Avnet Silica | Analog to Digital Converter 12 bit SAR 2 MSPS Differential SPI 165 V to 36 V 8 Pins X2QFN (Alt: NCD98010XMXTAG) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 33 Weeks, 0 Days | Silica - 0 |
|
Buy Now |
Part Details for NCD98010XMXTAG
NCD98010XMXTAG CAD Models
NCD98010XMXTAG Part Data Attributes
|
|
NCD98010XMXTAG
onsemi
Buy Now
Datasheet
|
Compare Parts:
NCD98010XMXTAG
onsemi
12-Bit Low Power SAR ADC Unsigned Output X2QFN, X2QFN8, 1.5x1.5, 0.5P, 5000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | X2QFN8, 1.5x1.5, 0.5P | |
| Manufacturer Package Code | 722AM | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 32 Weeks | |
| Date Of Intro | 2020-03-18 | |
| Samacsys Manufacturer | onsemi | |
| Analog Input Voltage-Max | 3.6 V | |
| Analog Input Voltage-Min | -1.65 V | |
| Converter Type | ADC, SUCCESSIVE APPROXIMATION | |
| JESD-30 Code | S-XQCC-N8 | |
| JESD-609 Code | e4 | |
| Length | 1.5 mm | |
| Linearity Error-Max (EL) | 0.048828125% | |
| Moisture Sensitivity Level | 1 | |
| Number of Analog In Channels | 1 | |
| Number of Bits | 12 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 120 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Bit Code | BINARY | |
| Output Format | SERIAL | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VQCCN | |
| Package Equivalence Code | LCC8,.06SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Sample Rate | 2 MHz | |
| Sample and Hold / Track and Hold | SAMPLE | |
| Seated Height-Max | 0.4 mm | |
| Supply Current-Max | 0.15 mA | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.5 mm |
