MT9V115EBKSTC-CR Information
MT9V115EBKSTC-CR by onsemi is an Image Sensor.
Image Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for MT9V115EBKSTC-CR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
31AC0118
|
Newark | Vga 1/13Cis Soc/ Ctray |Onsemi MT9V115EBKSTC-CR RoHS: Not Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$2.3000 | Buy Now |
|
DISTI #
5556-MT9V115EBKSTC-CR-ND
|
DigiKey | IC SENSOR IMAGE VGA COLOR Min Qty: 1 Lead time: 20 Weeks Container: Tray |
3970 In Stock |
|
$2.4494 / $3.8900 | Buy Now |
|
DISTI #
MT9V115EBKSTC-CR
|
Avnet Americas | Image Sensor Color CMOS 648x488Pixels 25-Pin ODCSP Tray - Trays (Alt: MT9V115EBKSTC-CR) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 16 Weeks, 0 Days Container: Tray | 8000 Factory Stock |
|
$2.0891 / $2.2180 | Buy Now |
|
DISTI #
863-MT9V115EBKSTC-CR
|
Mouser Electronics | Image Sensors VGA 1/13CIS SOC RoHS: Compliant | 0 |
|
$2.4500 | Order Now |
|
|
Onlinecomponents.com | RoHS: Compliant | 0 |
|
$2.2200 / $6.2300 | Buy Now |
|
DISTI #
87724987
|
Verical | Image Sensor Color CMOS 648x488Pixels 25-Pin ODCSP Tray RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 | Americas - 8000 |
|
$2.1761 | Buy Now |
|
DISTI #
MT9V115EBKSTC-CR
|
Avnet Silica | Image Sensor Color CMOS 648x488Pixels 25Pin ODCSP Tray (Alt: MT9V115EBKSTC-CR) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 17 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
MT9V115EBKSTC-CR
|
EBV Elektronik | Image Sensor Color CMOS 648x488Pixels 25Pin ODCSP Tray (Alt: MT9V115EBKSTC-CR) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 18 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for MT9V115EBKSTC-CR
MT9V115EBKSTC-CR CAD Models
MT9V115EBKSTC-CR Part Data Attributes
|
|
MT9V115EBKSTC-CR
onsemi
Buy Now
Datasheet
|
Compare Parts:
MT9V115EBKSTC-CR
onsemi
CMOS Image Sensor System-on-Chip, VGA, 1/13", ODCSP-25, 4000-CTRAY
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | ODCSP-25 | |
| Manufacturer Package Code | 570BK | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | IT ALSO OPERATES AT ANALOG SUPPLY VOLTAGE 2.5-3.1 V; ELECTRONIC ROLLING SHUTTER | |
| Array Type | FRAME | |
| Dynamic Range | 64 dB | |
| Frame Rate | 30 fps | |
| Horizontal Pixel | 648 | |
| JESD-609 Code | e1 | |
| Operating Current-Max | 9.5 mA | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -30 °C | |
| Optical Format | 1/13 inch | |
| Output Interface Type | 2-WIRE INTERFACE | |
| Output Range | 0.40-2.50V | |
| Output Type | DIGITAL VOLTAGE | |
| Pixel Size | 1.75X1.75 µm | |
| Sensors/Transducers Type | IMAGE SENSOR,CMOS | |
| Spectral Response (nm) | 390-1090 | |
| Supply Voltage-Max | 1.95 V | |
| Supply Voltage-Min | 1.7 V | |
| Terminal Finish | TIN SILVER COPPER | |
| Vertical Pixel | 488 |
