MM3Z27VT1G Information
MM3Z27VT1G by onsemi is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for MM3Z27VT1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
31Y2916
|
Newark | Zener Single Diode, 27 V, 300 Mw, Sod-323, 2 %, 2, 150 C Rohs Compliant: Yes |Onsemi MM3Z27VT1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 1 Container: Reel | 6000 |
|
$0.0270 / $0.0310 | Buy Now |
|
DISTI #
85W2827
|
Newark | Diode, Zener, 27V, 200Mw, Sod-323-2, Zener Voltage Nom:27V, Power Dissipation:300Mw, Diode Case Style:Sod-323, No. Of Pins:2Pins, Operating Temperature Max:150°C, Diode Mounting:Surface Mount, Product Range:Mm3Zxxxt1G Series Rohs Compliant: Yes |Onsemi MM3Z27VT1G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 58 |
|
$0.0050 | Buy Now |
|
DISTI #
67H6870
|
Newark | Zener Diode, 200Mw, 27V, Sod-323, Full Reel, Zener Voltage Nom:27V, Power Dissipation:300Mw, Diode Case Style:Sod-323, No. Of Pins:2Pins, Operating Temperature Max:150°C, Product Range:Mm3Z2 Series, Qualification:Aec-Q101 Rohs Compliant: Yes |Onsemi MM3Z27VT1G RoHS: Compliant Min Qty: 12000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0210 | Buy Now |
|
DISTI #
MM3Z27VT1GOSCT-ND
|
DigiKey | DIODE ZENER 27V 300MW SOD323 Min Qty: 1 Lead time: 5 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
42547 In Stock |
|
$0.0165 / $0.1100 | Buy Now |
|
DISTI #
85W2827
|
Avnet Americas | Zener Single Diode, 27 V, 300 mW, SOD-323, 2 Pins, 150 ?C, Surface Mount - Product that comes on tape, but is not reeled (Alt: 85W2827) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 41 Weeks, 0 Days Container: Ammo Pack | 58 Partner Stock |
|
$0.0370 | Buy Now |
|
DISTI #
MM3Z27VT1G
|
Avnet Americas | Zener Single Diode, 27 V, 300 mW, SOD-323, 2 Pins, 150 ?C, Surface Mount - Tape and Reel (Alt: MM3Z27VT1G) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 5 Weeks, 0 Days Container: Reel | 0 |
|
$0.0141 / $0.0163 | Buy Now |
|
DISTI #
863-MM3Z27VT1G
|
Mouser Electronics | Zener Diodes 27V 200mW RoHS: Compliant | 12420 |
|
$0.0160 / $0.1100 | Buy Now |
|
DISTI #
E02:0323_00077619
|
Arrow Electronics | Diode Zener Single 27V 5% 500mW 2-Pin SOD-323 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 5 Weeks | Europe - 33000 |
|
$0.0164 / $0.0182 | Buy Now |
|
DISTI #
V36:1790_07290252
|
Arrow Electronics | Diode Zener Single 27V 5% 500mW 2-Pin SOD-323 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 5 Weeks Date Code: 2415 | Americas - 18000 |
|
$0.0148 | Buy Now |
|
DISTI #
V72:2272_07290252
|
Arrow Electronics | Diode Zener Single 27V 5% 500mW 2-Pin SOD-323 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 5 Weeks Date Code: 2039 Container: Cut Strips | Americas - 10740 |
|
$0.0444 / $0.0528 | Buy Now |
Part Details for MM3Z27VT1G
MM3Z27VT1G CAD Models
MM3Z27VT1G Part Data Attributes
|
|
MM3Z27VT1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
MM3Z27VT1G
onsemi
200mW 5% Zener, SOD323, SOD-323 2 LEAD, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOD-323 2 LEAD | |
| Pin Count | 2 | |
| Manufacturer Package Code | 477-02 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 41 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| Dynamic Impedance-Max | 80 Ω | |
| Forward Voltage-Max (VF) | 0.9 V | |
| JESD-30 Code | R-PDSO-G2 | |
| JESD-609 Code | e3 | |
| Knee Impedance-Max | 300 Ω | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.3 W | |
| Qualification Status | Not Qualified | |
| Reference Voltage-Nom | 27 V | |
| Reverse Current-Max | 0.05 µA | |
| Reverse Test Voltage | 18.9 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tol-Max | 7.04% | |
| Working Test Current | 2 mA |
Alternate Parts for MM3Z27VT1G
This table gives cross-reference parts and alternative options found for MM3Z27VT1G. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MM3Z27VT1G, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| BZX84C27S-7-F | Diodes Incorporated | $0.0441 | Zener Diode, 27V V(Z), 7.04%, 0.2W, Silicon, Unidirectional, GREEN, ULTRA SMALL, PLASTIC PACKAGE-6 | MM3Z27VT1G vs BZX84C27S-7-F |
| MM3Z27VT1 | onsemi | Check for Price | 27V, 0.2W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE, 0.067 X 0.049 INCH, 0.035 INCH HEIGHT, PLASTIC, CASE 477-02, 2 PIN | MM3Z27VT1G vs MM3Z27VT1 |
| BZT52C27S-7 | Diodes Incorporated | Check for Price | Zener Diode, 27V V(Z), 7.04%, 0.2W, Silicon, Unidirectional, ULTRA SMALL, PLASTIC PACKAGE-2 | MM3Z27VT1G vs BZT52C27S-7 |
| BZX384-C27 | General Instrument Corp | Check for Price | Zener Diode, 27V V(Z), 5%, 0.2W, Silicon, Unidirectional, | MM3Z27VT1G vs BZX384-C27 |
| CMDZ27LBK | Central Semiconductor Corp | Check for Price | Zener Diode, 27V V(Z), 7.037%, 0.25W, Silicon, Unidirectional, SOD-323, 2 PIN | MM3Z27VT1G vs CMDZ27LBK |
| BZM55C27 | Lite-On Semiconductor Corporation | Check for Price | Zener Diode, 27V V(Z), 7.04%, 0.5W, Silicon, Unidirectional, HERMETIC SEALED, GLASS, MICROMELF-2 | MM3Z27VT1G vs BZM55C27 |
| BZM55C27-13 | Diodes Incorporated | Check for Price | Zener Diode, 27V V(Z), 7.04%, 0.5W, Silicon, Unidirectional, HERMETIC SEALED, GLASS, MICROMELF-2 | MM3Z27VT1G vs BZM55C27-13 |
| TCMM5Z27V | Tak Cheong Electronics (Holdings) Co Ltd | Check for Price | Zener Diode, 27V V(Z), 7.03%, 0.2W, Silicon, Unidirectional, GREEN, PLASTIC PACKAGE-2 | MM3Z27VT1G vs TCMM5Z27V |
| BZX84C27S | Lite-On Semiconductor Corporation | Check for Price | Zener Diode, 27V V(Z), 0.2W, Silicon, Unidirectional, PLASTIC, SOT-363, 6 PIN | MM3Z27VT1G vs BZX84C27S |
| BZM55C27-7 | Diodes Incorporated | Check for Price | Zener Diode, 27V V(Z), 7.04%, 0.5W, Silicon, Unidirectional, HERMETIC SEALED, GLASS, MICROMELF-2 | MM3Z27VT1G vs BZM55C27-7 |
