Part Details for MC74LCX74DTR2G by onsemi
Results Overview of MC74LCX74DTR2G by onsemi
- Distributor Offerings: (29 listings)
- Number of FFF Equivalents: (2 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (7 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Aerospace and Defense
Energy and Power Systems
Healthcare
MC74LCX74DTR2G Information
MC74LCX74DTR2G by onsemi is an FF/Latch.
FF/Latches are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for MC74LCX74DTR2G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
71J5663
|
Newark | Ic, flip-Flop, dual, d Type, lcx/Lvc-Cmos, tssop,14Pin, plastic Rohs Compliant: Yes |Onsemi MC74LCX74DTR2G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1370 / $0.1820 | Buy Now |
|
DISTI #
10N9462
|
Newark | Ic, D-Type Flip Flop, Dual, 7Ns Tssop-14, Flip-Flop Type:D, Propagation Delay:7Ns, Frequency:150Mhz, Output Current:24Ma, Ic Case/Package:Tssop, No. Of Pins:14Pins, Trigger Type:Positive Edge, Supply Voltage Min:2.3V, Msl:- Rohs Compliant: Yes |Onsemi MC74LCX74DTR2G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$0.1520 / $0.1950 | Buy Now |
|
DISTI #
MC74LCX74DTR2GOSCT-ND
|
DigiKey | IC FF D-TYPE DBL 1-BIT 14-TSSOP Min Qty: 1 Lead time: 9 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
1840 In Stock |
|
$0.1321 / $0.5300 | Buy Now |
|
DISTI #
863-MC74LCX74DTR2G
|
Mouser Electronics | Flip Flops 2-3.6V CMOS Dual D-Type RoHS: Compliant | 7717 |
|
$0.1350 / $0.3300 | Buy Now |
|
|
Future Electronics | 74LCX Series 2.3 to 3.6 V CMOS Dual D-Type Flip-Flop - TSSOP-14 RoHS: Compliant pbFree: Yes Min Qty: 2500 Package Multiple: 2500 Lead time: 9 Weeks Container: Reel | 5000Reel |
|
$0.1300 / $0.1360 | Buy Now |
|
|
Onlinecomponents.com | Low Voltage CMOS Dual D Flip-Flop RoHS: Compliant | 0 |
|
$0.1266 / $0.1428 | Buy Now |
|
DISTI #
85995293
|
Verical | Flip Flop D-Type Pos-Edge 2-Element 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 2019 Package Multiple: 1 | Americas - 137500 |
|
$0.1388 / $0.1858 | Buy Now |
|
DISTI #
85996696
|
Verical | Flip Flop D-Type Pos-Edge 2-Element 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 2019 Package Multiple: 1 Date Code: 0701 | Americas - 40000 |
|
$0.1388 / $0.1858 | Buy Now |
|
DISTI #
86004621
|
Verical | Flip Flop D-Type Pos-Edge 2-Element 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 2019 Package Multiple: 1 Date Code: 0601 | Americas - 22500 |
|
$0.1388 / $0.1858 | Buy Now |
|
DISTI #
85994229
|
Verical | Flip Flop D-Type Pos-Edge 2-Element 14-Pin TSSOP W T/R RoHS: Compliant Min Qty: 2019 Package Multiple: 1 Date Code: 1201 | Americas - 10499 |
|
$0.1388 / $0.1858 | Buy Now |
Part Details for MC74LCX74DTR2G
MC74LCX74DTR2G CAD Models
MC74LCX74DTR2G Part Data Attributes
|
|
MC74LCX74DTR2G
onsemi
Buy Now
Datasheet
|
Compare Parts:
MC74LCX74DTR2G
onsemi
Low Voltage CMOS Dual D Flip-Flop, TSSOP-14, 2500-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | TSSOP-14 | |
| Package Description | TSSOP-14 | |
| Pin Count | 14 | |
| Manufacturer Package Code | 948G | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 9 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Family | LVC/LCX/Z | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e4 | |
| Length | 5 mm | |
| Load Capacitance (CL) | 50 pF | |
| Logic IC Type | D FLIP-FLOP | |
| Max I(ol) | 0.024 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 1 | |
| Number of Functions | 2 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Polarity | COMPLEMENTARY | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP14,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Prop. Delay@Nom-Sup | 7 ns | |
| Propagation Delay (tpd) | 8.4 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 2 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Trigger Type | POSITIVE EDGE | |
| Width | 4.4 mm | |
| fmax-Min | 150 MHz |
