MAX3232CUE+T by:

3.0V to 5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers, 16-TSSOP_4.4-4.4_MM, 16 Pins, 0 to 70C

Part Details for MAX3232CUE+T by Analog Devices Inc

Results Overview of MAX3232CUE+T by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

MAX3232CUE+T Information

MAX3232CUE+T by Analog Devices Inc is a Line Driver or Receiver.
Line Driver or Receivers are under the broader part category of Drivers And Interfaces.

A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.

Price & Stock for MAX3232CUE+T

Part # Distributor Description Stock Price Buy
DISTI # 700-MAX3232CUET
Mouser Electronics RS-232 Interface IC 3.0V to 5.5V, Low-Power, up to 1Mbps, Tr RoHS: Compliant 26282
  • 1 $7.1600
  • 10 $5.5300
  • 25 $5.1200
  • 100 $4.4700
  • 250 $4.1400
  • 500 $4.0500
  • 1,000 $4.0000
  • 2,500 $3.9400
$3.9400 / $7.1600 Buy Now
Analog Devices Inc 3.0V to 5.5V, Low-Power, up to Min Qty: 1 Package Multiple: 1 408
  • 1 $7.1600
  • 10 $5.5240
  • 25 $5.1152
  • 100 $4.6654
  • 250 $4.4510
  • 500 $4.3217
  • 1,000 $4.2153
  • 2,500 $4.1030
$4.1030 / $7.1600 Buy Now

Part Details for MAX3232CUE+T

MAX3232CUE+T CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MAX3232CUE+T Part Data Attributes

Parametric Data
MAX3232CUE+T Analog Devices Inc
Buy Now Datasheet
Compare Parts:
MAX3232CUE+T Analog Devices Inc 3.0V to 5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers, 16-TSSOP_4.4-4.4_MM, 16 Pins, 0 to 70C
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code 16-TSSOP_4.4-4.4_MM
Package Description 4.40 MM, 0.65 MM PITCH, LEAD FREE, MO-153AC, TSSOP-16
Pin Count 16
Manufacturer Package Code 16-TSSOP_4.4-4.4_MM
Reach Compliance Code compliant
Date Of Intro 1996-05-23
Samacsys Manufacturer Analog Devices
Differential Output NO
Driver Number of Bits 2
Input Characteristics SCHMITT TRIGGER
Interface IC Type LINE TRANSCEIVER
Interface Standard EIA-232; EIA-562
JESD-30 Code R-PDSO-G16
JESD-609 Code e3
Length 5 mm
Moisture Sensitivity Level 1
Number of Functions 2
Number of Terminals 16
Operating Temperature-Max 70 °C
Operating Temperature-Min
Out Swing-Min 10 V
Output Low Current-Max 0.0016 A
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP16,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Receiver Number of Bits 2
Seated Height-Max 1.1 mm
Supply Current-Max 1 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 3 V
Supply Voltage-Nom 3.3 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 4.4 mm

Alternate Parts for MAX3232CUE+T

This table gives cross-reference parts and alternative options found for MAX3232CUE+T. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MAX3232CUE+T, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MAX3232EUE+ Analog Devices Inc $4.4393 3.0V to 5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers, 16-TSSOP_4.4-4.4_MM, 16 Pins, -40 to 85C MAX3232CUE+T vs MAX3232EUE+
MAX3232CUE+T Maxim Integrated Products $4.8190 Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, LEAD FREE, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232CUE+T
MAX3232EUE+T Analog Devices Inc $5.7139 3.0V to 5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers, 16-TSSOP_4.4-4.4_MM, 16 Pins, -40 to 85C MAX3232CUE+T vs MAX3232EUE+T
MAX3232CUE-T Maxim Integrated Products Check for Price Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232CUE-T
MAX3232EUE+T Maxim Integrated Products Check for Price Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, LEAD FREE, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232EUE+T
MAX3232EUE-T Maxim Integrated Products Check for Price Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232EUE-T
MAX3232EUE Maxim Integrated Products Check for Price Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232EUE
MAX3232CUE Maxim Integrated Products Check for Price Line Transceiver, 1 Func, 2 Driver, 2 Rcvr, CMOS, PDSO16, 4.40 MM, 0.65 MM PITCH, MO-153AC, TSSOP-16 MAX3232CUE+T vs MAX3232CUE
Part Number Manufacturer Composite Price Description Compare
MAX3232IPW Texas Instruments $0.9717 3- to 5.5-V dual channel 250kbps RS-232 line driver/receiver with +/-15-kV ESD protection 16-TSSOP -40 to 85 MAX3232CUE+T vs MAX3232IPW
ST3232BWR STMicroelectronics Check for Price 3 TO 5.5V, LOW POWER, UP TO 400KBPS RS-232 DRIVERS AND RECEIVERS, [-40oC, 85oC] TEMPERATURE RANGE MAX3232CUE+T vs ST3232BWR
ICL3232EIV-20Z-T Renesas Electronics Corporation Check for Price Line Transceiver MAX3232CUE+T vs ICL3232EIV-20Z-T
SP3222EHCA-L/TR Sipex Corporation Check for Price Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, PDSO20, LEAD FREE, PLASTIC, SSOP-20 MAX3232CUE+T vs SP3222EHCA-L/TR
ICL3232EIV-16 Intersil Corporation Check for Price DUAL LINE TRANSCEIVER, PDSO16, PLASTIC, MO-153AB, TSSOP-16 MAX3232CUE+T vs ICL3232EIV-16
MAX3232CPWRE4 Texas Instruments Check for Price 3- to 5.5-V dual channel 250kbps RS-232 line driver/receiver with +/-15-kV ESD protection 16-TSSOP 0 to 70 MAX3232CUE+T vs MAX3232CPWRE4
MAX3224ECAP Maxim Integrated Products Check for Price Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, BICMOS, PDSO20, 5.30 MM, MO-150, SSOP-20 MAX3232CUE+T vs MAX3224ECAP
ISL83385ECA Rochester Electronics LLC Check for Price Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, CMOS, PDSO20, PLASTIC, MO-150AE, SSOP-20 MAX3232CUE+T vs ISL83385ECA
MAX3232ECUE+T Maxim Integrated Products Check for Price Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, BICMOS, PDSO16, 4.40 MM, MO-153, TSSOP-16 MAX3232CUE+T vs MAX3232ECUE+T
ICL3223CV Rochester Electronics LLC Check for Price Line Transceiver, 2 Func, 2 Driver, 2 Rcvr, CMOS, PDSO20, PLASTIC, MO-153AC, TSSOP-20 MAX3232CUE+T vs ICL3223CV
