Part Details for M24256-BWDW6TP by STMicroelectronics
Results Overview of M24256-BWDW6TP by STMicroelectronics
- Distributor Offerings: (16 listings)
- Number of FFF Equivalents: (10 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Computing and Data Storage
M24256-BWDW6TP Information
M24256-BWDW6TP by STMicroelectronics is an EEPROM.
EEPROMs are under the broader part category of Memory Components.
Memory components are essential in electronics for computer processing. They can be volatile or non-volatile, depending on the desired function. Read more about Memory Components on our Memory part category page.
Price & Stock for M24256-BWDW6TP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-8622-1-ND
|
DigiKey | IC EEPROM 256KBIT I2C 8TSSOP Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1637 In Stock |
|
$0.2907 / $0.3900 | Buy Now |
|
DISTI #
M24256-BWDW6TP
|
Avnet Americas | EEPROM Serial-I2C 256K-bit 32K x 8 3.3V/5V 8-Pin TSSOP T/R - Tape and Reel (Alt: M24256-BWDW6TP) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 10 Weeks, 0 Days Container: Reel | 72000 |
|
$0.1478 | Buy Now |
|
DISTI #
511-M24256-BWDW6TP
|
Mouser Electronics | EEPROM 512Kb and 256Kb Ser RoHS: Compliant | 3723 |
|
$0.2990 / $0.4500 | Buy Now |
|
DISTI #
E02:0323_00208992
|
Arrow Electronics | EEPROM Serial-I2C 256K-bit 32K x 8 3.3V/5V 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 10 Weeks Date Code: 2401 | Europe - 4000 |
|
$0.2356 / $0.2467 | Buy Now |
|
|
STMicroelectronics | 256 Kbit Serial I2C Bus EEPROM COO: France RoHS: Compliant Min Qty: 1 | 2823 |
|
$0.3200 / $0.3800 | Buy Now |
|
|
Future Electronics | M24256 Series 256 Kb (32 K x 8) 2.5 V SMT Serial I²C Bus EEPROM - TSSOP-8 RoHS: Compliant pbFree: Yes Min Qty: 4000 Package Multiple: 4000 Lead time: 10 Weeks Container: Reel | 4000Reel |
|
$0.1770 / $0.1840 | Buy Now |
|
DISTI #
87902778
|
Verical | EEPROM Serial-I2C 256K-bit 32K x 8 3.3V/5V 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Date Code: 2401 | Americas - 4000 |
|
$0.2371 / $0.2483 | Buy Now |
|
|
Bristol Electronics | 4428 |
|
RFQ | ||
|
|
Quest Components | 32K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8 | 26 |
|
$0.5250 / $0.6300 | Buy Now |
|
|
Future Electronics | M24256 Series 256 Kb (32 K x 8) 2.5 V SMT Serial I�C Bus EEPROM - TSSOP-8 Min Qty: 4000 Package Multiple: 4000 |
4000 null |
|
$0.1770 / $0.1840 | Buy Now |
Part Details for M24256-BWDW6TP
M24256-BWDW6TP CAD Models
M24256-BWDW6TP Part Data Attributes
|
|
M24256-BWDW6TP
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
M24256-BWDW6TP
STMicroelectronics
256 Kbit Serial I<sup>2</sup>C Bus EEPROM
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | SOIC | |
| Package Description | TSSOP-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.32.00.51 | |
| Factory Lead Time | 10 Weeks | |
| Date Of Intro | 1980-01-04 | |
| Samacsys Manufacturer | STMicroelectronics | |
| Clock Frequency-Max (fCLK) | 1 MHz | |
| Data Retention Time-Min | 200 | |
| Endurance | 4000000 Write/Erase Cycles | |
| I2C Control Byte | 1010DDDR | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e4 | |
| Length | 4.4 mm | |
| Memory Density | 262144 bit | |
| Memory IC Type | EEPROM | |
| Memory Width | 8 | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Number of Words | 32768 words | |
| Number of Words Code | 32000 | |
| Operating Mode | SYNCHRONOUS | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Organization | 32KX8 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Parallel/Serial | SERIAL | |
| Peak Reflow Temperature (Cel) | 260 | |
| Programming Voltage | 5 V | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 mm | |
| Serial Bus Type | I2C | |
| Standby Current-Max | 0.000002 A | |
| Supply Current-Max | 0.0025 mA | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 2.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm | |
| Write Cycle Time-Max (tWC) | 5 ms | |
| Write Protection | HARDWARE |
