LTE3401HX Information
LTE3401HX by NXP Semiconductors is a Cellular Telephone Circuit.
Cellular Telephone Circuits are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for LTE3401HX
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
37AC4226
|
Newark | Sige:C Low Noise Amplifier Mmic With Bypass Switch For Lte/ Reel Rohs Compliant: Yes |Nxp LTE3401HX RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1720 / $0.1770 | Buy Now |
|
DISTI #
79AK4761
|
Newark | Rf Amplifier, 1.452 To 2.69Ghz, Xson-6 Rohs Compliant: Yes |Nxp LTE3401HX RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$0.4610 | Buy Now |
|
DISTI #
LTE3401HX
|
Avnet Americas | MMIC - Tape and Reel (Alt: LTE3401HX) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 111 Weeks, 0 Days Container: Reel | 0 |
|
$0.1557 / $0.1610 | Buy Now |
|
DISTI #
V72:2272_18754306
|
Arrow Electronics | RF Amp Single MMIC Amp 2.69GHz 3.1V 6-Pin XSON T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 99 Weeks Date Code: 2117 Container: Cut Strips | Americas - 1225 |
|
$0.1693 / $0.1894 | Buy Now |
|
DISTI #
LTE3401HX
|
Richardson RFPD | RF & MW LNA RoHS: Compliant Min Qty: 1 | 0 |
|
RFQ | |
|
DISTI #
LTE3401HX
|
EBV Elektronik | MMIC (Alt: LTE3401HX) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 54 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for LTE3401HX
LTE3401HX CAD Models
LTE3401HX Part Data Attributes
|
|
LTE3401HX
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
LTE3401HX
NXP Semiconductors
RF and Baseband Circuit
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Package Description | XSON-6 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.33.00.01 | |
| Factory Lead Time | 111 Weeks | |
| Date Of Intro | 2018-10-26 | |
| Samacsys Manufacturer | NXP | |
| JESD-30 Code | R-PBCC-B6 | |
| Length | 1.1 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | BCC | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 0.4 mm | |
| Supply Voltage-Nom | 1.8 V | |
| Surface Mount | YES | |
| Telecom IC Type | RF AND BASEBAND CIRCUIT | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | BUTT | |
| Terminal Pitch | 0.4 mm | |
| Terminal Position | BOTTOM | |
| Width | 0.7 mm |
