LMT87LPGM Information
LMT87LPGM by Texas Instruments is a Temperature Sensor.
Temperature Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for LMT87LPGM
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-LMT87LPGMCT-ND
|
DigiKey | SENSOR ANALOG -50C-150C TO92-3 Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Tape & Reel (TR) |
28722 In Stock |
|
$0.3076 / $0.7000 | Buy Now |
|
DISTI #
595-LMT87LPGM
|
Mouser Electronics | Board Mount Temperature Sensors +/-2C 2.7V to 5.5V a nalog output tempera RoHS: Compliant | 10126 |
|
$0.3170 / $0.5000 | Buy Now |
|
DISTI #
V72:2272_18291012
|
Arrow Electronics | Temperature Sensor Analog Automotive 3-Pin TO-92 Ammo RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 1727 Container: Cut Strips | Americas - 3210 |
|
$0.1398 / $0.2874 | Buy Now |
|
DISTI #
LMT87LPGM
|
Chip One Stop | Semiconductors RoHS: Compliant pbFree: Yes Min Qty: 5 Lead time: 0 Weeks, 1 Days Container: Cut Tape | 3000 |
|
$0.2150 | Buy Now |
Part Details for LMT87LPGM
LMT87LPGM CAD Models
LMT87LPGM Part Data Attributes
|
|
LMT87LPGM
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LMT87LPGM
Texas Instruments
±2°C 2.7V to 5.5V analog output temperature sensor with -13.6 mV/°C gain 3-TO-92 -50 to 150
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Accuracy-Max (Cel) | 2.7 Cel | |
| Additional Feature | AEC-Q100; SHORT CIRCUIT PROTECTION | |
| Body Breadth | 1.52 mm | |
| Body Height | 5.05 mm | |
| Body Length or Diameter | 4 mm | |
| Housing | PLASTIC | |
| JESD-609 Code | e3 | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Terminals | 3 | |
| Operating Current-Max | 0.0081 mA | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -50 °C | |
| Package Shape/Style | RECTANGULAR | |
| Sensors/Transducers Type | TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 2.7 V | |
| Surface Mount | NO | |
| Terminal Finish | Matte Tin (Sn) | |
| Termination Type | SOLDER |
LMT87LPGM Frequently Asked Questions (FAQ)
-
Texas Instruments recommends a 2-layer PCB with a solid ground plane on the bottom layer and a small thermal pad on the top layer connected to the GND pin. This layout helps to dissipate heat efficiently and reduce thermal resistance.
-
To minimize the effects of vibration on temperature readings, it's recommended to use a rigid PCB and secure the LMT87LPGM to the board using a sturdy mechanical attachment. Additionally, consider using a low-pass filter to reduce noise and vibrations.
-
The maximum cable length for the digital output of the LMT87LPGM depends on the specific application and the noise environment. As a general guideline, Texas Instruments recommends keeping the cable length below 10 inches (25 cm) to minimize signal degradation and noise pickup.
-
While the LMT87LPGM is rated for operation up to 150°C, it's not recommended to use it in environments above this temperature. Prolonged exposure to high temperatures can affect the device's accuracy and reliability. If you need to measure temperatures above 150°C, consider using a different temperature sensor designed for high-temperature applications.
-
The LMT87LPGM is factory-calibrated and does not require additional calibration. However, if you need to achieve high accuracy, you can perform a system-level calibration by measuring the temperature sensor's output at multiple points and adjusting the readings accordingly. Consult the datasheet and application notes for more information on calibration procedures.
