KDZVTR5.6B by: ROHM Semiconductor

Zener Diode, 5.95V V(Z), 5.88%, 1W, Silicon, Unidirectional, SC-109B, 2 PIN

Part Details for KDZVTR5.6B by ROHM Semiconductor

Results Overview of KDZVTR5.6B by ROHM Semiconductor

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Energy and Power Systems Electronic Manufacturing Renewable Energy Automotive

KDZVTR5.6B Information

KDZVTR5.6B by ROHM Semiconductor is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
