IX4426NTR Information
IX4426NTR by Littelfuse Inc is an MOSFET Driver.
MOSFET Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for IX4426NTR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
27AK1452
|
Newark | Gate Driver Ic, 4.5V - 35V, Soic, No. Of Channels:2Channels, Gate Driver Type:-, Driver Configuration:Low Side, Power Switch Type:Mosfet, No. Of Pins:8Pins, Ic Case/Package:Soic, Ic Mounting:Surface Mount, Input Type:Cmos, Ttl Rohs Compliant: Yes |Littelfuse IX4426NTR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 1176 |
|
$0.4160 | Buy Now |
|
DISTI #
25AJ5541
|
Newark | Dual Low-Sd Ultr Non Invrtng Drvr 1.5A/ Tr Rohs Compliant: Yes |Littelfuse IX4426NTR RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.4710 / $0.5550 | Buy Now |
|
DISTI #
5656-IX4426NTRCT-ND
|
DigiKey | IC GATE DRVR LOW-SIDE 8SOIC Min Qty: 1 Lead time: 18 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
4564 In Stock |
|
$0.4694 / $1.8600 | Buy Now |
|
DISTI #
V36:1790_07768433
|
Arrow Electronics | Driver 1.5A 2-OUT Low Side Inv 8-Pin SOIC T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 18 Weeks Date Code: 2433 | Americas - 10000 |
|
$0.4313 / $0.4808 | Buy Now |
|
DISTI #
75577477
|
RS | DUAL LOW-SD ULTR NON INVRTNG DRVR 1.5A Min Qty: 2000 Package Multiple: 1 Lead time: 8 Weeks, 0 Days Container: Bulk | 0 |
|
$0.6300 / $0.6800 | RFQ |
|
DISTI #
84981822
|
Verical | Driver 1.5A 2-OUT Low Side Inv 8-Pin SOIC T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2433 | Americas - 10000 |
|
$0.4313 / $0.4808 | Buy Now |
Part Details for IX4426NTR
IX4426NTR CAD Models
IX4426NTR Part Data Attributes
|
|
IX4426NTR
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
IX4426NTR
Littelfuse Inc
Buffer/Inverter Based MOSFET Driver, 1.5A, PDSO8, SOIC-8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | LITTELFUSE | |
| High Side Driver | NO | |
| Interface IC Type | BUFFER OR INVERTER BASED IGBT/MOSFET DRIVER | |
| JESD-30 Code | R-PDSO-G8 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 2 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Peak Current Limit-Nom | 1.5 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max | 30 V | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 18 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Turn-off Time | 60 µs | |
| Turn-on Time | 60 µs | |
| Width | 3.9 mm |
